Electrical System
9.22
534D-9, 534D-10 & 544D
778
723
2
Engine Speed Sensor (Camshaft) Error - Erratic
779
703
11
Auxiliary Equipment Sensor Input #3 (OEM Switch)
784
1590
2
Loss of Communication with Adaptive Cruise Control
951
166
2
Cylinder Power Imbalance Between Cylinders
957
27
2
EGR Valve Position - Erratic
958
2795
2
VGT Position Sensor - Erratic
1117
627
2/2
Power Lost Without Ignition Off - Erratic
1139
651
7
Injector Solenoid Driver Cylinder 1 - Not Responding
1141
652
7
Injector Solenoid Driver Cylinder 2 - Not Responding
1142
653
7
Injector Solenoid Driver Cylinder 3 - Not Responding
1143
654
7
Injector Solenoid Driver Cylinder 4 - Not Responding
1144
655
7
Injector Solenoid Driver Cylinder 5 - Not Responding
1145
656
7
Injector Solenoid Driver Cylinder 6 - Not Responding
1228
27
2/2
EGR Valve Position - Erratic
1229
2795
2/2
VGT Position Sensor - Erratic
1239
2623
3/3
Accelerator Pedal or Lever Position Sensor 2 Circuit - High
1241
2623
4/4
Accelerator Pedal or Lever Position Sensor 2 Circuit - Low
1242
091
2/2
Accelerator Pedal or Lever Position Sensor Number 1 and 2 - Erratic
1633
625
2
Komnet Datalink Cannot Transmit
1639
703
11
Auxiliary Equipment Sensor Input Number 3 (OEM Switch)
1654
1323
11/31
Engine Misfire Cylinder 1
1655
1324
11/31
Engine Misfire Cylinder 2
1656
1325
11/31
Engine Misfire Cylinder 3
1657
1326
11/31
Engine Misfire Cylinder 4
1658
1327
11/31
Engine Misfire Cylinder 5
1659
1328
11/31
Engine Misfire Cylinder 6
1663
3241
11/31
Catalyst Inlet Temperature Sensor Swapped with Outlet
1664
3050
11/31
Catalyst Missing
1665
3241
4
Exhaust Gas Temperature 1 Circuit - Low
1666
3241
3
Exhaust Gas Temperature 1 Circuit - High
1667
3241
2
Exhaust Gas Temperature 1 - Erratic
1668
1761
4/4
Catalyst Tank Level Sensor Circuit - Low
1669
1761
3
Catalyst Tank Level Sensor Circuit - High
1671
1761
1/18
Catalyst Tank Level - Low - Moderately Severe
1673
1761
1
Catalyst Tank Level - Low - Most Severe
1674
3249
4
Exhaust Gas Temperature 2 Circuit - Low
1675
3249
3
Exhaust Gas Temperature 2 Circuit - High
1676
3249
2
Exhaust Gas Temperature 2 Circuit - Erratic
1677
3031
4
Catalyst Tank Temperature - Low
1678
3031
3
Catalyst Tank Temperature - High
1679
3031
2
Catalyst Tank Temperature - Erratic
1681
3361
12
Catalyst Dosing Control Unit
Fault Code
SPN Code
FMI Code
Description
