388 Brocade MLX Series and Brocade NetIron XMR Hardware Installation Guide
53-1002373-02
Hardware specifications for Brocade NetIron XMR routers
9
• Inrush current: 45A peak maximum at 25 degrees C (77 degrees F)
Table 62 lists the maximum power calculations for Brocade NetIron XMR routers.
Table 63 lists the maximum power consumption, in watts, for individual components within a
Brocade NetIron XMR router.
TABLE 62 Brocade NetIron XMR router power consumption values
Model @100 VAC @200 VAC @ 48 VDC
Amps Watts BTU/hr Amps Watts BTU/hr Amps Watts BTU/hr
Brocade NetIron XMR 4000 14 1384 4724 7 1384 4724 29 1384 4724
Brocade NetIron XMR 8000 28 2750 9386 14 2750 9386 57 2740 9386
Brocade NetIron XMR 16000 56 5572 19017 28 5572 19017 116 5572 19017
Brocade NetIron XMR 32000 N/A N/A N/A 57 11353 38476 237 11353 38476
TABLE 63 Maximum power consumption for Brocade NetIron XMR router components
Component Maximum power
consumption, in watts
Management modules
MR management module (Brocade NetIron XMR 4000, 8000 and 16000) 30W
MR management module (Brocade NetIron XMR 32000) 35W
MR2 management module (BR-MLX-MR-X for Brocade NetIron XMR 4000, 8000 and
16000) 40W
MR2 management module (BR-MLX-32-MR2-X for Brocade NetIron XMR 32000) 45W
Switch fabric modules
NI-X-SF1 switch fabric module (Brocade NetIron XMR 4000, 8000, and 16000) 19W
NI-X-SF3 switch fabric module (Brocade NetIron XMR 4000, 8000, and 16000) 53W
NI-X-32-SF switch fabric module (Brocade NetIron XMR 32000) 60W
High-speed switch fabric modules
NI-X-4-HSF 19W
NI-X-16-8-HSF 53W
NI-X-32-HSF 60W
POS interface modules
1-port POS OC192 125W
2-port POS OC192 220W
2-port POS OC48 115W
4-port POS OC48 132W
8-port POS OC48 230W
Interface modules
1-port 100 Gbps Ethernet interface module 485W
2-port 10 Gbps Ethernet interface module with fiber-optic transceivers 150W
4-port 10 Gbps Ethernet interface module with fiber-optic transceivers 245W
