Brocade MLX-16 router components
You can install the following components in the router slots:
•
Up to two management modules (one active and one redundant).
•
Up to four switch fabric modules.
•
Up to 16 interface modules.
•
Up to eight power supplies (AC or DC).
displays the Brocade MLX-16 router.
FIGURE 7
Brocade MLX-16 router
1-16 Interface slots 1-16
20 Switch fabric slot 4
24-31 Power supplies
17
Switch fabric slot 1
21 Management slot 1
18
Switch fabric slot 2
22 Management slot 2
19
Switch fabric slot 3
23 ESD connector
12
13
14
15
16
17
18
19
20
21
22
23
1
2
3
4
5
6
7
8
9
10
11
24
28
25
29
26
30
27
31
