Cable routing for the lower-left quadrant
1. Route cables from slots #18 and #17 directly to the left through the side comb. Refer to
FIGURE 200
Routing lower-left quadrant cables
1
Lower left quadrant
3
Cables from slot #18
2
Cables from slot #17
4
Side combs (18)
1
2
3
4
