USER’S GUIDE
5-56
9. Retain the cover plate and two screws removed in Step 2 in case
you want to remove the MIO card later.
Fig. 5-72 Installing the MIO Card
RAM Expansion
This printer has 64 Mbytes of memory standard and 2 slots for optional
expansion memory. The memory can be expanded up to 320 Mbytes by
installing commercially available dual in-line memory modules
(DIMMs). (The standard memory fitted can vary depending on the printer
model and country.)
This printer uses memory module which is:
100 pins, no-parity, SDRAM with 64Mbit or more.
This printer is not compatible with Extended Data Output (EDO) DIMM,
or DIMM which uses 16Mbit SDRAM.
The following capacity of DIMM can be installed:
• 16 Mbyte TECHWORKS PM-HP 16M-BR
• 32 Mbyte TECHWORKS PM-HP 32M-BR
• 64 Mbyte TECHWORKS PM-HP 64M-BR
• 128 Mbyte TECHWORKS PM-HP 128M-BR
In general, the DIMM must have the following specifications:
Type: 100 pin and 32 bit output
CAS Latency: 2 or 3
Clock Frequency: 66Mhz or more
Capacity: 16,32, 64 or 128 Mbyte
Height: 46mm (1.8 inches) or less
Parity: NONE
Dram Type: 64 M bit SDRAM 4 Bank
SDRAM can be used.
✒ Notes
•
There might be some DIMMs which will not work with this printer.
•
For more informationabout the memory cards consult the dealer
where you purchased the printer.
• For the latest information: http://www.brother.com
