Instruction 24-9448 4-17
Operation
4.13.2 Recalling Logged Test Data
Recall ndvdual logged combuston test data records as follows:
1. Dsplay the MAIN MENU by pressng the
MENU (F2) button. If necessary, press ESC
untl MENU appears above F2.
2. Use the buttons to hghlght MEMORY,
and then press ENT to dsplay the MEMORY
MENU.
3. Use the buttons to hghlght LOGGING
DIRECTORY, and then press ENT to dsplay
the LOGGING DIRECTORY screen.
4. Use the buttons to hghlght the desred
data loggng locaton to be recalled. Each
loggng locaton s dentfed by the date and
tme at whch the data was saved. The word
EMPTY sgnfes that the loggng locaton
does not contan data.
5. Press ENT to dsplay the loggng data con-
taned n the selected memory locaton.
Note the followng:
• The top lne of the log test data screen shows
the log locaton beng vewed. In ths exam-
ple, “Log: 6” s beng dsplayed.
• The ENT button can be pressed to vew other
log test data screens.
• The recalled logged test data can be prnted
by pressng the PRINT (F1) button (refer to
Secton 4.16).
MAIN MENU
FUEL
PRESSURE
MEMORY
SETUP
CALIBRATION
DIAGNOSTICS
STATUS
F1 F2 F3
MENU
MEMORY MENU
MEMORY DIRECTORY
LOGGING DIRECTORY
CLEAR MEMORY DATA
CLEAR LOGGING DATA
CLEAR ALL MEMORY
F1 F2 F3
MENU
LOGGING DIRECTORY
1 05/23/06 10:00:00
2 05/23/06 10:30:00
3 05/23/06 11:00:00
4 05/23/06 11:30:00
5 05/23/06 12:00:00
6 05/23/06 12:30:00
7 05/23/06 01:00:00
(more)
F1 F2 F3
PAGE- MENU PAGE+
Log: 6 NATURAL GAS
O
2
4.0 %
CO 12 ppm
EFF 82.6 %
CO
2
9.5 %
T-STK 374 °F
T-AIR 68.0 °F
EA
21.3 %
CO(3) 13 ppm
PRINT MENU
F1 F2 F3
