4.13.1 Recalling Combustion Test Data
Recall ndvdual combuston test data records as follows:
1. Dsplay the MAIN MENU by pressng the
MENU (F2) button. If necessary, press ESC
untl MENU appears above F2.
2. Use the buttons to hghlght MEMORY,
and then press ENT to dsplay the MEMORY
MENU.
3. Use the buttons to hghlght MEMORY
DIRECTORY, and then press ENT to dsplay
the MEMORY DIRECTORY screen.
4. Use the buttons to hghlght the desred
memory locaton to be recalled. Each memory
locaton s dentfed by the date and tme
at whch data was saved. The word EMPTY
sgnfes that the memory locaton does not
contan data.
5. Press ENT to dsplay the data contaned n
the selected memory locaton.
Note the followng:
• The top lne of the recalled combuston test
data screen shows the memory locaton beng
vewed. In ths example, “MEM: 1” s beng
dsplayed
• The ENT button can be pressed to vew other
memory test data screens.
• The recalled combuston test data can be
prnted by pressng the PRINT (F1) button
(refer to Secton 4.16).
MAIN MENU
FUEL
PRESSURE
MEMORY
SETUP
CALIBRATION
DIAGNOSTICS
STATUS
F1 F2 F3
MENU
MEMORY MENU
MEMORY DIRECTORY
LOGGING DIRECTORY
CLEAR MEMORY DATA
CLEAR LOGGING DATA
CLEAR ALL MEMORY
F1 F2 F3
MENU
MEMORY DIRECTORY
1 05/23/06 10:00:00
2 05/23/06 10:30:14
3 05/23/06 11:45:38
4 05/23/06 01:50:10
5 05/23/06 03:35:25
6 EMPTY
7 EMPTY
(more)
F1 F2 F3
PAGE- MENU PAGE+
Mem: 1 NATURAL GAS
O
2
4.0 %
CO 12 ppm
EFF 82.6 %
CO
2
9.5 %
T-STK 374 °F
T-AIR 68.0 °F
EA
21.3 %
CO(3) 13 ppm
PRINT MENU
F1 F2 F3
