Initial Setup
3.4 Operating Parameters
The PCA 2 s set up at the factory for the followng operatng parameters:
Fuel . . . . . . . . . . . . . . . . . . . . .Natural Gas
Temperature Unts . . . . . . . . .°F
Pressure Unts . . . . . . . . . . . .Inches of Water Column (nwc)
Polluton Unts . . . . . . . . . . . .ppm
Date . . . . . . . . . . . . . . . . . . . . .Current MM/DD/YY
Tme . . . . . . . . . . . . . . . . . . . .Current EST HH:MM AM/PM
O
2
Reference . . . . . . . . . . . . . .0%
Prnt Pressure . . . . . . . . . . . .No
Zoom . . . . . . . . . . . . . . . . . . . .No
Battery Charger . . . . . . . . . . .OFF
Loggng . . . . . . . . . . . . . . . . . .No
Button Sound . . . . . . . . . . . . .ON
To change any of these parameters, perform the assocated procedure pro-
vded n Sectons 3.5 thru 3.16.
3.5 Fuel Selection
To assure the accurate calculaton of combuston
effcency, select the fuel beng burned as follows:
1. Dsplay the MAIN MENU by pressng the
MENU (F2) button. If necessary, press ESC
untl MENU appears above F2.
2. Use the buttons to hghlght FUEL, and
then press ENT to dsplay the FUEL MENU.
3. Use the buttons to scroll through the
lst of avalable fuels untl the desred
fuel s hghlghted. In the example shown,
PROPANE has been selected.
TIP: Use the buttons to quickly scroll to the
bottom and top of the list.
4. Press ENT to save the selecton and dsplay
the Combuston Test HOLD screen. Observe
that the name of the selected fuel should now
appear at the top of the screen.
MAIN MENU
FUEL
PRESSURE
MEMORY
SETUP
CALIBRATION
DIAGNOSTICS
STATUS
F1 F2 F3
MENU
FUEL MENU
NATURAL GAS
OIL #2
OIL #4
OIL #6
PROPANE
COAL
WOOD
(more)
MENU
F1 F2 F3
