Norgren 200 Series Nugget Spool Valves - Manual (Page 8)

Nugget 200 Spool Valves
VAL-10-8 Littleton, CO USA Phone: 303-794-2611 www.norgren.com
Solenoid Pilot Operated Inline Valves
Pilot
Port Pressure Weight Repair
Description Symbol Type Size Body* Operator psig (bar) lbs. (kg) Kit
Single
1/4" K41DA00 KS1-KV2
35 - 150 2.22
54237-59
Solenoid 3-Port/ (2.4 - 10.3) (1.01)
Spring 2-Position
3/8" K41EA00 KS1-KV2
35 - 150 2.22
54237-59 Return
(2.4 - 10.3) (1.01)
1/4" K71DA00 KS6-KV2
35 - 150 2.22
54237-56
(2.4 - 10.3) (1.01)
5-Port/
3/8" K71EA00 KS6-KV2
35 - 150 2.22
54237-56
2-Position (2.4 - 10.3) (1.01)
1/2" K71FA00 KS6-KV2
35 - 150 4.40
54237-56
(2.4 - 10.3) (2.00)
Double
1/4" K41DA00 KV2-KV2
15 - 150 4.40
54237-59
Solenoid 3-Port/ (1.0 - 10.3) (2.00)
(Non- 2-Position
3/8" K41EA00 KV2-KV2
15 - 150 4.40
54237-59 Detented) (1.0 - 10.3) (2.00)
1/4" K71DA00 KV2-KV2
15 - 150 2.22
54237-56
(1.0 - 10.3) (1.01)
5-Port/
3/8" K71EA00 KV2-KV2
15 - 150 4.40
54237-56
2-Position (1.0 - 10.3) (2.00)
1/2" K71FA00 KV2-KV2
15 - 150 2.22
54237-56
(1.0 - 10.3) (1.01)
1/4" K81DA00 KV0-KV0
15 - 150 4.40
54237-56
5-Port/
(1.0 - 10.3) (2.00)
3-Position
3/8" K81EA00 KV0-KV0
1.0 - 10.3 4.40
54237-56
All Ports (15 - 150) (2.00)
Blocked
1/2" K81FA00 KV0-KV0
15 - 150 4.40
54237-56
(1.0 - 10.3) (2.00)
1/4" K81DA05 KV0-KV0
15 - 150 4.40
54237-57
5-Port/
(1.0 - 10.3) (2.00)
3-Position
3/8" K81EA05 KV0-KV0
15 - 150 4.40
54237-57
Inlet Open (1.0 - 10.3) (2.00)
to Cylinder
1/2" K81FA05 KV0-KV0
15 - 150 4.40
54237-57
(1.0 - 10.3) (2.00)
1/4" K81DA06 KV0-KV0
15 - 150 2.22
54237-58
5-Port/
(1.0 - 10.3) (1.01)
3-Position
3/8" K81EA06 KV0-KV0
15 - 150 4.40
54237-58
Cyl Open (1.0 - 10.3) (2.00)
to Exhaust
1/2" K81FA06 KV0-KV0
15 - 150 4.40
54237-58
(1.0 - 10.3) (2.00)
Double
1/4" K41DA00 KVL-KVL
25 - 150 4.40
54237-59
Solenoid 3-Port/ (1.7 - 10.3) (2.00)
(Detented) 2-Position
3/8" K41EA00 KVL-KVL
25 - 150 4.40
54237-59
(1.7 - 10.3) (2.00)
1/4" K71DA00 KVL-KVL
25 - 150 2.22
54237-56
(1.7 - 10.3) (1.01)
5-Port/
3/8" K71EA00 KVL-KVL
25 - 150 2.22
54237-56
2-Position (1.7 - 10.3) (1.01)
1/2" K71FA00 KVL-KVL
25 - 150 2.22
54237-56
(1.7 - 10.3) (1.01)
12 10
2
1 3
12
2 4
3 1 5
14
12
2 4
3 1 5
14
2 4
1 5 3
14 12
2 4
1 5 3
14 12
2
1 3
12 10
2 4
3 1 5
14 12
12
2
1 3
10
* Standard valves are equipped with PTF threads, solenoid operators with locking overrides, internal pilot, 120V/60 Hz-110V/50 Hz coils and cable grip connectors.
Optional solenoid operators, coil voltages and electrical connectors can be ordered using the information on p. VAL-10-11/12. Solenoid specifications given on
pp. VAL-10-6/7.
Note: For ISO-G threads, insert “G” in the 5th position. 1/2" ported bodies are not available with ISO G threads.
