Nugget 200 Spool Valves
VAL-10-20 Littleton, CO USA Phone: 303-794-2611 www.norgren.com
Air Pilot Operated Inline Valves
Pilot
Port Pressure Weight Repair
Description Symbol Type Size Body* Operator psig (bar) lbs. (kg) Kit
Single
1/4" K41DA00 KS1-KA2
35 - 150 2.22
54237-59
Air 3-Port/ (2.4 - 10.3) (1.01)
Spring 2-Position
3/8" K41EA00 KS1-KA2
35 - 150 2.22
54237-59 Return
(2.4 - 10.3) (1.01)
1/4" K71DA00 KS6-KA2
35 - 150 2.22
54237-56
(2.4 - 10.3) (1.01)
5-Port/
3/8" K71EA00 KS6-KA2
35 - 150 2.22
54237-56
2-Position (2.4 - 10.3) (1.01)
1/2" K71FA00 KS6-KA2
35 - 150 2.22
54237-56
(2.4 - 10.3) (1.01)
Double
1/4" K41DA00 KA2-KA2
15 - 150 2.22
54237-59
Air 3-Port/ (1.0 - 10.3) (1.01)
(Non- 2-Position
3/8" K41EA00 KA2-KA2
15 - 150 2.22
54237-59
Detented) (1.0 - 10.3) (1.01)
1/4" K71DA00 KA2-KA2
15 - 150 2.22
54237-56
(1.0 - 10.3) (1.01)
5-Port/
3/8" K71EA00 KA2-KA2
15 - 150 2.22
54237-56
2-Position (1.0 - 10.3) (1.01)
1/2" K71FA00 KA2-KA2
15 - 150 2.22
54237-56
(1.0 - 10.3) (1.01)
1/4" K81DA00 KAC-KAC
45 - 150 4.40
54237-56
5-Port/
(3.1 - 10.3) (2.00)
3-Position
3/8" K81EA00 KAC-KAC
45 - 150 4.40
54237-56
All Ports (3.1 - 10.3) (2.00)
Blocked
1/2" K81FA00 KAC-KAC
45 - 150 4.40
54237-56
(3.1 - 10.3) (2.00)
1/4" K81DA05 KAC-KAC
45 - 150 4.40
54237-57
5-Port/
(3.1 - 10.3) (2.00)
3-Position
3/8" K81EA05 KAC-KAC
45 - 150 4.40
54237-57
Inlet Open (3.1 - 10.3) (2.00)
to Cylinder
1/2" K81FA05 KAC-KAC
45 - 150 4.40
54237-57
(3.1 - 10.3) (2.00)
1/4" K81DA06 KAC-KAC
45 - 150 4.40
54237-58
5-Port/
(3.1 - 10.3) (2.00)
3-Position
3/8" K81EA06 KAC-KAC
45 - 150 4.40
54237-58
Cyl Open (3.1 - 10.3) (2.00)
to Exhaust
1/2" K81FA06 KAC-KAC
45 - 150 4.40
54237-58
(3.1 - 10.3) (2.00)
Double
1/4" K41DA00 KAA-KAA
25 - 150 2.22
54237-59
Air 3-Port/ (1.7 - 10.3) (1.01)
(Detented) 2-Position
3/8" K41EA00 KAA-KAA
25 - 150 2.22
54237-59
(1.7 - 10.3) (1.01)
1/4" K71DA00 KAA-KAA
25 - 150 2.22
54237-56
(1.7 - 10.3) (1.01)
5-Port/
3/8" K71EA00 KAA-KAA
25 - 150 2.22
54237-56
2-Position (1.7 - 10.3) (1.01)
1/2" K71FA00 KAA-KAA
25 - 150 2.22
54237-56
(1.7 - 10.3) (1.01)
2
1 3
2 4
3 1 5
2 4
3 1 5
2 4
1 5 3
2 4
1 5 3
2
1 3
2 4
3 1 5
2
1 3
* Standard valves are equipped with PTF threads, solenoid operators with locking overrides, internal pilot, 120V/60 Hz-110V/50 Hz coils and cable grip connectors.
Optional solenoid operators, coil voltages and electrical connectors can be ordered using the information on p. VAL-10-11/12.
Note: For ISO-G threads, insert “G” in the 5th position. 1/2" ported bodies are not available with ISO G threads.
2 4
1 5 3
