Nugget 200 Spool Valves
VAL-10-10 Littleton, CO USA Phone: 303-794-2611 www.norgren.com
Solenoid Pilot Operated Stacking Valves With Junction Box
Pilot
Port Pressure Weight Repair
Description Symbol Type Size Body* Operator psig (bar) lbs. (kg) Kit
Single 5-Port/ 1/4" K79DA80 KS6-K72
35 - 150 .53
54237-56
Solenoid 2-Position (2.4 - 150) (.24)
Spring No Lights
3/8" K79EA80 KS6-K72
35 - 150 .53
54237-56 Return
(2.4 - 150) (.24)
5-Port/ 1/4" K79DA50 KS6-KM1
35 - 150 .53
54237-56
2-Position (2.4 - 150) (.24)
One Light
3/8" K79EA50 KS6-KM1
35 - 150 .53
54237-56
(2.4 - 150) (.24)
Double 5-Port/ 1/4" K79DA80 K72-K72
15 - 150 .53
54237-56
Solenoid 2-Position (1.0 - 10.3) (.24)
(Non- No Lights
3/8" K79EA80 K72-K72
15 - 150 .53
54237-56 Detented) (1.0 - 10.3) (.24)
5-Port/ 1/4" K79DA50 KM1-KM1
15 - 150 .53
54237-56
2-Position (1.0 - 10.3) (.24)
Two Lights
3/8" K79EA50 KM1-KM1
15 - 150 .53
54237-56
(1.0 - 10.3) (.24)
Double All Ports
1/4" K89DA80 K70-K70
15 - 150 .53
54237-56
Solenoid Blocked (1.0 - 10.3) (.24)
(Non-
No Lights
3/8" K89EA80 K70-K70
15 - 150 .53
54237-56 Detented
(1.0 - 10.3) (.24)
5-Port/ All Ports
1/4" K89DA50 KM8-KM8
15 - 150 .53
54237-56
3-Position Blocked (1.0 - 10.3) (.24)
Common Two Lights
3/8" K89EA50 KM8-KM8
15 - 150 .53
54237-56 Inlet & (1.0 - 10.3) (.24)
Exhaust -
Inlet
1/4" K89DA85 K70-K70
15 - 150 .53
54237-57 Ports 1,3,5
Open to Cyl (1.0 - 10.3) (.24)
No Lights
3/8" K89EA85 K70-K70
15 - 150 .53
54237-57
(1.0 - 10.3) (.24)
Inlet
1/4" K89DA55 KM8-KM8
15 - 150 .53
54237-57
Open to Cyl (1.0 - 10.3) (.24)
Two Lights
3/8" K89EA55 KM8-KM8
15 - 150 .53
54237-57
(1.0 - 10.3) (.24)
Cyl Open
1/4" K89DA86 K70-K70
15 - 150 .53
54237-58
to Exhaust (1.0 - 10.3) (.24)
No Lights
3/8" K89EA86 K70-K70
15 - 150 .53
54237-58
(1.0 - 10.3) (.24)
Cyl Open
1/4" K89DA56 KM8-KM8
15 - 150 .53
54237-58
to Exhaust
(1.0 - 10.3) (.24)
Two Lights
3/8" K89EA56 KM8-KM8
15 - 150 .53
54237-58
(1.0 - 10.3) (.24)
Double 5-Port/ 1/4" K79DA80 K7L-K7L
25 - 150 .53
54237-56
Solenoid 2-Position (1.7 - 10.3) (.24)
(Detented) No Lights
3/8" K79EA80 K7L-K7L
25 - 150 .53
54237-56
(1.7 - 10.3) (.24)
5-Port/ 1/4" K79DA50 KM6-KM6
25 - 150 .53
54237-56
2-Position (1.7 - 10.3) (.24)
Two Lights
3/8" K79EA50 KM6-KM6
25 - 150 .53
54237-56
(1.7 - 10.3) (.24)
12
2 4
3 1 5
14
2 4
1 5 3
14 12
2 4
1 5 3
14 12
2 4
1 5 3
14 12
2 4
3 1 5
14 12
12
2 4
3 1 5
14
* Standard valves are equipped with PTF threads, solenoid operators with locking overrides, internal pilot, 120V/60 Hz-110V/50 Hz coils and cable grip connectors.
Optional solenoid operators, coil voltages and electrical connectors can be ordered using the information on p. VAL-10-11/12. Solenoid specifications given on
pp. VAL-10-6/7.
Note: For ISO-G threads, insert “G” in the 5th position.
