Nugget 200 Spool Valves
VAL-10-12 Littleton, CO USA Phone: 303-794-2611 www.norgren.com
Electrical Connectors for KQx Series Solenoid
Operators – Order With Numbers
To order solenoid connectors for KQx Series Operators, specify the
desired solenoid connector part number listed below in addition to the
desired valve model number, e. g. K41DA00-KQ1-KQ12VC
CSA Certified Electrical Connectors for
KQx Series Solenoid Operators
Single/Dual
Rotatable Cable Grip Connector . . . . . . . . . . . . . . . . . . . . . . . .1VC/2VC
1/2" NPT Conduit Connector . . . . . . . . . . . . . . . . . . . . . . . . . . .1V2/2V2
Rotatable Cable Grip with Indicator Light,
110V AC/DC only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1C3/2C3
24V AC/DC only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1C2/2C2
12V AC/DC only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1C1/2C1
220V AC/DC only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1C4/2C4
Optional KQx Series Electrical Connectors
Non-CSA Certified
5-Foot Molded Cord Connector 1V1/2V1
KQx Series Accessories
– Non-CSA Certified
Extended Locking Override – Black Knob with
Stainless Steel Plunger
Contact Application Engineering
Optional Coil Voltages
Additional Part Number Characters
Standard Wattage Low Wattage
KVx, K1x, K3x, K5x, KUx, K0x, K2x,
& K7x Series K4x, & K6x Series KDx, Series KQx Series KMx Series KXx Series
Operators Operators Operators Operators Operators Operators
Voltages Single Double Single Double Single Double Single Double Single Double Single Double
60 Hz 50 Hz DC Solenoid Solenoid Solenoid Solenoid Solenoid Solenoid Solenoid Solenoid Solenoid Solenoid Solenoid Solenoid
120 110 – Standard Standard 1WH 2WH Standard Standard Standard Standard Standard Standard – –
240 220 – 1W6 2W6 – – 1TE 2TE 1T2 2T2 1TN 2TN 1NH 2NH
12 12 – 1W3 2W3 – – – – – – – – – –
24 24 – 1W4 2W4 1WJ 2WJ 1TD 2TD 1T1 2T1 1TM 2TM – –
48 48 – 1W5 2W5 – – – – – – – – – –
– 240 – – – – – – – 1T3 2T3 – – – –
120 100 – – – – – – – – – – – Standard Standard
– – 6 1W7 2W7 1WK 2WK 1TF 2TF 1T4 2T4 – – 1N7 2N7
– – 12 1W1 2W1 1WF 2WF 1T6 2T6 1T5 2T5 1TS 2TS 1NA 2NA
– – 24 1W2 2W2 Standard 1TH 2TH 1T6 2T6 1TT 2TT 1ND 2ND
– – 48 – – – – 1TJ 2TJ 1T7 2T7 1TU 2TU – –
– – 115 – – 1WL 2WL 1TK 2TK 1T8 2T8 1TX 2TX – –
– – 10.5 – – – – – – 1T9 2T9 – – – –
Example: On K41DA00-KS6-KV1, change from standard 110VAC to 240VAC by adding 1W6 to the part number. New part number becomes K41DA00-KS6-KV11W6
Wattage Connector Type Override
Standard Low No Cable Conduit 5' Molded Locking Non Locking
Watt Watt Connector Grip
KY0 X X X
KY1 X X X
KY2 X X X
KY3 X X X
KY5 X X X
KY5 X X X
KY6 X X X
KY7 X X X
KY8 X X X
KY9 X X X
KYA X X X
KYB X X X
KYC X X X
KYD X X X
KYE X X X
KYF X X X
Lightweight Plastic* Solenoid Operator
* Polyphthalamide resin (PPA)
