Norgren 200 Series Nugget Spool Valves - Manual (Page 31)

Nugget 200 Spool Valves
All Dimensions in Inches (mm)
Littleton, CO USA Phone: 303-794-2611 www.norgren.com VAL-10-31
Manual Operators
.38 (9.7)
TRAVEL
3.34
(84.8)
KB0/KB5 – PALM BUTTON
1.38
(35.1)
2.30
(58.4)
KB3/KB5
KB0/KB2
M20 x 1.5 – 6g
Pnl Mtg Hole – .81 (20.6)
Max Pnl Thk – .25 (6.4)
.38 (9.7)
TRAVEL
KK0, KK1
3.15
(80.0)
KK0/KK3 – KNOB
1.00
(25.4)
2.19
(55.6)
KK1
KK0
.19 (4.8) TRAVEL
.19 (4.8) KK2, KK3
KK2, KK3
2.99
(75.9)
Travel (2-position)
KL0, KL1
1.35
(34)
KL0/KL3 – LEVER
1.79
(45)
.90
(23)
.90
(23)
Travel (3-position)
KL2, KL3
2.5
(64)
3.5
(89)
KL0
KL1/KL3
3.90
(99)
1.00
(25)
Dia.
Travel (2-position)
KL5, KL6
.85
(22)
KL5/KL8 – LEVER
.80
(20)
.40
(10)
.40
(10)
Travel (3-position)
KL7, KL8
3.07
(78)
2.07
(53)
KL5
KL6/KL8
3.98
(101)
1.00
(25)
Dia.
KT0/KT2 – TREADLE
4.28
(108.7)
5.28
(134.1)
KT0
KT1/KT2
2.81
(71.4)
1.18 (30.0)
TRAVEL
7.42
(188.5) KF0 – FOOT PEDAL
1.58
(40.1)
.56 (14.2)
TRAVEL
5.04
(128.0)
