Norgren 200 Series Nugget Spool Valves - Manual (Page 13)

Littleton, CO USA Phone: 303-794-2611 www.norgren.com VAL-10-13
Nugget 200 Spool Valves
Replacement Coils
Solenoid Assemblies Ordered Separately
Includes coil, plunger, sleeve and seal
Standard Wattage Low Wattage
KVx, K1x, K3x, KUx, K0x, K2x, K4x,
Voltages K5x & K7x Series & K6x Series KDx, Series KQx Series KMx Series
Operators Operators Operators Operators Operators
60 Hz 50 Hz DC Coil Only Coil Only Coil Only Coil Only Coil Only
120 110 – 54452-01 54469-03 54944-21 54932-21 54960-21
240 220 – 54452-07 – 54944-23 54932-23 54960-23
12 12 – 54452-04 – – – –
24 24 – 54452-05 54469-04 54944-22 54932-22 54960-22
48 48 – 54452-06 – – – –
– 240 – –– – 54932-24 – –
120 100 – – – – –
240 208 – – – – – –
24 22 – – – – – 2362-07
– – 6 – 54469-05 54944-25 54932-25 –
– – 12 54452-02 54469-01 54944-26 54932-26 54960-26
– – 24 54452-03 54469-02 54944-27 54932-27 54960-27
– – 48 – – 54944-28 54932-28 54960-28
– – 115 – 54469-06 54944-29 54932-29 54960-29
– – 10.5 – – – 54932-30 –
Voltages KDx, Series KQx Series KMx Series KXx
60 Hz 50 Hz DC Operators Operators Operators Series
120 110 – 54944-01 54932-01 54960-01 53902-01
240 220 – 54944-03 54932-03 54960-03 53902-14
24 24 – 54944-02 54932-02 54960-02 –
– 240 – – 54932-04 – –
120 100 – – – – –
240 208 – – – – –
24 22 – – – – –
– – 6 54944-05 54932-05 54960-05 53902-10
– – 12 54944-06 54932-06 54960-06 53902-11
– – 24 54944-07 54932-07 54960-07 53902-12
– – 48 54944-08 54932-08 54960-08 –
– – 115 54944-09 54932-09 54960-09 –
– – 10.5 – 54932-10 – –
KUx/KVx, K0x/K1x, K2x/K3x, K4x/K5x,K6x/K7x Series Operators
Solenoid assemblies for these operators can be obtained by ordering a
replacement coil from the ordering information on this page. Appropriate solenoid
base, standard or low wattage assemblies can be ordered from the following table.
KVx, K1x, K3x, K5x KUx, K0x, K2x, K4x
& K7x Series & K6x Series
Replacement Bases Replacement Bases
Locking Override 54462-02 54462-04
Non-locking Override 54462-09 54462-10
