Norgren 200 Series Nugget Spool Valves - Manual (Page 27)

Nugget 200 Spool Valves
Littleton, CO USA Phone: 303-794-2611 www.norgren.com VAL-10-27
Manually Operated Inline Valves - Lever
Minimum
Port Operating Weight Repair
Description Symbol Type Size Body* Operator Force lbs. (kg) lbs. (kg) Kit
Spring
1/4" K41DA00 KS1-KL0
9.0 2.22
54237-59
Return 3-Port/ (4.1) (1.01)
(Non- 2-Position
3/8" K41EA00 KS1-KL0
9.0 2.22
54237-59
Detented (4.1) (1.01)
1/4" K71DA00 KS1-KL0
9.0 2.22
54237-56
(4.1) (1.01)
5-Port/
3/8" K71EA00 KS1-KL0
9.0 2.22
54237-56
2-Position (4.1) (1.01)
1/2" K71FA00 KS1-KL0
9.0 2.22
54237-56
(4.1) (1.01)
End Cap
1/4" K41DA00 KC0-KL0
9.0 2.22
54237-59
(Non- 3-Port/ (4.1) (1.01)
Detented) 2-Position
3/8" K41EA00 KC0-KL0
9.0 2.22
54237-59
(4.1) (1.01)
1/4" K71DA00 KC0-KL0
9.0 2.22
54237-56
(4.1) (1.01)
5-Port/
3/8" K71EA00 KC0-KL0
9.0 2.22
54237-56
2-Position (4.1) (1.01)
1/2" K71FA00 KC0-KL0
9.0 2.22
54237-56
(4.1) (1.01)
End Cap
1/4" K41DA00 KC0-KL1
7.0 2.22
54237-59
(Detented) 3-Port/ (4.1) (1.01)
2-Position
3/8" K41EA00 KC0-KL1
7.0 2.22
54237-59
(4.1) (1.01)
1/4" K71DA00 KC0-KL1
7.0 2.22
54237-56
(4.1) (1.01)
5-Port/
3/8" K71EA00 KC0-KL1
7.0 2.22
54237-56
(4.1) (1.01)
1/2" K71FA00 KC0-KL1
7.0 2.22
54237-56
(4.1) (1.01)
1/4" K81DA00 KC0-KL3
7.0 4.40
54237-56
5-Port/ (4.1) (2.00)
3-Position
3/8" K81EA00 KC0-KL3
7.0 4.40
54237-56
All Ports (4.1) (2.00)
Blocked
1/2" K81FA00 KC0-KL3
7.0 4.40
54237-56
(4.1) (2.00)
1/4" K81DA05 KC0-KL3
7.0 4.40
54237-57
5-Port/ (4.1) (2.00)
3-Position
3/8" K81EA05 KC0-KL3
7.0 4.40
54237-57
Inlet Open (4.1) (2.00)
to Cylinder
1/2" K81FA05 KC0-KL3
7.0 4.40
54237-57
(4.1) (2.00)
1/4" K81DA06 KC0-KL3
7.0 4.40
54237-58
5-Port/ (4.1) (2.00)
3-Position
3/8" K81EA06 KC0-KL3
7.0 4.40
54237-58
Cyl Open (4.1) (2.00)
to Exhaust
1/2" K81FA06 KC0-KL3
7.0 4.40
54237-58
(4.1) (2.00)
End Cap
1/4" K81DA00 KC0-KL2
7.0 4.40
54237-56
(Spring 5-Port/ (4.1) (2.00)
Centered) 3-Position
3/8" K81EA00 KC0-KL2
7.0 4.40
54237-56
All Ports (4.1) (2.00)
Blocked
1/2" K81FA00 KC0-KL2
7.0 4.40
54237-56
(4.1) (2.00)
1/4" K81DA05 KC0-KL2
7.0 4.40
54237-57
5-Port/ (4.1) (2.00)
3-Position
3/8" K81EA05 KC0-KL2
7.0 4.40
54237-57
Inlet Open (4.1) (2.00)
to Cylinder
1/2" K81FA05 KC0-KL2
7.0 4.40
54237-57
(4.1) (2.00)
1/4" K81DA06 KC0-KL2
7.0 4.40
54237-58
5-Port/ (4.1) (2.00)
3-Position
3/8" K81EA06 KC0-KL2
7.0 4.40
54237-58
Cyl Open (4.1) (2.00)
to Exhaust
1/2" K81FA06 KC0-KL2
7.0 4.40
54237-58
(4.1) (2.00)
10
2
1 3
2 4
3 1 5
2 4
3 1 5
2
1 3
2 4
3 1 5
2 4
1 5 3
2 4
1 5 3
2 4
1 5 3
2 4
1 5 3
2 4
1 5 3
2 4
1 5 3
2
1 3
* Standard valves are equipped with PTF threads, solenoid operators with locking overrides, internal pilot, 120V/60 Hz-110V/50 Hz coils and cable grip connectors.
Optional solenoid operators, coil voltages and electrical connectors can be ordered using the information on p. VAL-10-11/12.
Note: For ISO-G threads, insert “G” in the 5th position. 1/2" ported bodies are not available with ISO G threads.
