Nugget 200 Spool Valves
Littleton, CO USA Phone: 303-794-2611 www.norgren.com VAL-10-11
Operator Operating Weight Repair
Position
ISO G PTF
Description Pressure psig (bar) lbs. (kg) Kit
Standard Solenoid Operator with Rotatable Grip Connector*
2-Position
KVB KV1 non-locking override, nondetented, internal pilot
15 - 150 .53
54344-17
Valves (1.03 - 10.3) (.24)
KVC KV2 locking override, nondetented, internal pilot
15 - 150 .53
54344-17
(1.03 - 10.3) (.24)
KVE KV4 non-locking override, nondetented, external pilot
10" Hg - 150 .53
54344-17
(Vacuum - 10.3) (.24)
KVF KV5 locking override, nondetented, external pilot
10" Hg - 150 .53
54344-17
(Vacuum - 10.3) (.24)
KVG KV6 non-locking override, detented, internal pilot
15 - 150 .53
54344-17
(1.03 - 10.3) (.24)
KVN KVL locking override, detented, internal pilot
15 - 150 .53
54344-17
(1.03 - 10.3) (.24)
3-Position
KVJ KV8 non-locking override, spring centered, internal pilot
15 - 150 .53
54344-17
Valves (1.03 - 10.3) (.24)
KVA KV0 locking override, spring centered, internal pilot
15 - 150 .53
54344-17
(1.03 - 10.3) (.24)
KVD KV3 non-locking override, spring centered, external pilot
10" Hg - 150 .53
54344-17
(Vacuum - 10.3) (.24)
Standard Solenoid Operator without Electrical Connector*
2-Position
K1B K11 non-locking override, nondetented, internal pilot
15 - 150 .53
54344-17
Valves (1.03 - 10.3) (.24)
K1G K16 non-locking override, detented, internal pilot
15 - 150 .53
54344-17
(1.03 - 10.3) (.24)
K1N K1L locking override, detented, internal pilot
15 - 150 .53
54344-17
(1.03 - 10.3) (.24)
3-Position
K1A K10 locking override, spring centered, internal pilot
15 - 150 .53
54344-17
Valves (1.03 - 10.3) (.24)
Standard Solenoid Operator with Rotatable 1/2" Conduit Connector*
2-Position
K3B K31 non-locking override, nondetented, internal pilot
15 - 150 .53
54344-17
Valves (1.03 - 10.3) (.24)
K3C K32 locking override, nondetented, internal pilot
15 - 150 .53
54344-17
(1.03 - 10.3) (.24)
K3E K34 non-locking override, nondetented, external pilot
10" Hg - 150 .53
54344-17
(Vacuum - 10.3) (.24)
K3F K35 locking override, nondetented, external pilot
10" Hg - 150 .53
54344-17
(Vacuum - 10.3) (.24)
K3G K36 non-locking override, detented, internal pilot
1.03 - 10.3 .53
54344-17
(15 - 150) (.24)
K3N K3L locking override, detented, internal pilot
1.03 - 10.3 .53
54344-17
(15 - 150) (.24)
K3P K3M locking override, detented, external pilot
10" Hg - 150 .53
54344-17
(Vacuum - 10.3) (.24)
3-Position
K3J K38 non-locking override, spring centered, internal pilot
1.03 - 10.3 .80
54344-17
Valves (15 - 150) (.36)
K3A K30 locking override, spring centered, internal pilot
1.03 - 10.3 .80
54344-17
(15 - 150) (.36)
Standard Solenoid Operator with Molded Cord Connector, 1.6 mm (5'3") Connector Cable*
2-Position
K5C K52 locking override, nondetented, internal pilot
1.03 - 10.3 .80
54344-17
Valves (15 - 150) (.36)
K5F K55 locking override, nondetented, external pilot
10" Hg - 150 .80
54344-17
(Vacuum - 10.3) (.36)
K5N K5L locking override, detented, internal pilot
15 - 150 .80
54344-17
(1.03 - 10.3) (.36)
3-Position
K5A K50 locking override, spring centered, internal pilot
15 - 150 .82
54344-17
Valves (1.03 - 10.3) (.37)
CSA Certified Solenoid Operator with Fixed 1/2" Conduit Connector Molded into Cord**
2-Position
KDB KD1 non-locking override, nondetented, internal pilot
15 - 150 .60
54344-17
Valves (1.03 - 10.3) (.27)
KDC KD2 locking override, nondetented, internal pilot
15 - 150 .60
54344-17
(1.03 - 10.3) (.27)
CSA Certified Solenoid Operator without Electrical Connector**†
2-Position
KQB KQ1 non-locking override, nondetented, internal pilot
15 - 150 .61
54344-17
Valves (1.03 - 10.3) (.28)
KQC KQ2 locking override, nondetented, internal pilot
15 - 150 .61
54344-17
(1.03 - 10.3) (.28)
KQG KQ6 non-locking override, detented, internal pilot
15 - 150 .61
54344-17
(1.03 - 10.3) (.28)
3-Position
KQJ KQ8 non-locking override, spring centered, internal pilot
15 - 150 .62
54344-17
Valves (1.03 - 10.3) (.29)
Hazardous Location Solenoid Operator**
2-Position
KXB KX1 non-locking override, nondetented, internal pilot
15 - 150 1.48
53478-07
Valves (1.03 - 10.3) (.67)
KXC KX2 locking override, nondetented, internal pilot
15 - 150 1.48
53478-07
(1.03 - 10.3) (.67)
3-Position
KXJ KX8 non-locking override, spring centered, internal pilot
15 - 150 1.49
53478-07
Valves (1.03 - 10.3) (.68)
Solenoid Pilot Operators
* Standard voltage is 110/1250 AC 50/60 Hz. For optional voltages add three characters to the end of the part number. See p. VAL-10-12. For low wattage
options contact Application Engineering.
** For external pilot options contact Application Engineering.
† Electrical connectors for KQX series solenoid operators see VAL-10-12.
