Nugget 200 Spool Valves
VAL-10-6 Littleton, CO USA Phone: 303-794-2611 www.norgren.com
Solenoid Operator Specifications
KVx/KUx, K0x/K1x, K2x/K3x, K4x/K5x, & K6x/K7x Series
Voltages Available and Power Requirements:
Standard: 120V/60Hz-110V/50Hz: 7W
Optional: KVx, K1x, K3x, K5x, & K7x Series
12V/60Hz/50Hz: 7W
24V/60Hz/50Hz: 7W
48V/60Hz/50 Hz: 7W
240V/60Hz: 7W
220V/50Hz: 7W
12 VDC: 6W
24 VDC: 6W
Low Wattage: KUx, K0x, K2x, K4x, & K6x Series
Standard: 24 VDC: 2W
Optional: 24V/50Hz/60Hz: 3.5W
120V/60Hz: 3.5W
110V/50Hz: 3.5W
6 VDC: 2W
12 VDC: 2W
115 VDC: 3.4W
Duty: Continuous at 90 to 105% of rated voltage
Coil Type: Class H. Molded with three-pin plug-in connector
Enclosure Classification: NEMA 4, per DIN 40050 – IP 65
Connector Plug:
KUx/KVx Series:
Standard,Cable grip for cables 1/4" to 5/16"
(6 to 8 mm) in diameter
K2x/K3x Series: Rotatable 1/2" Conduit Connector
K4x/K5x Series: Class H. Molded with three-pin plug-in
connector
Override: Manual, locking
Pilot Supply: Internal - standard, External - optional
External Pilot Supply Port: 1/8" PTF (ISO G Optional).
Minimum Electrical Signal Duration: Solenoid operated
2-position detented or nondetented valves can be shifted with a
momentary electrical signal. Minimum signal duration is 13 milliseconds
for single solenoid operated spring return valves. Double solenoid
operated valves minimum signal duration is 20 milliseconds.
Electrical connector spades on the operator coil are 3-pin with 11 mm
spacing.
KDx & KQx Series
Voltages Available and Power Requirements:
Standard: 120V/60Hz: 6W
Optional:
24V/60Hz/50Hz: 6W
12VDC: 6W
24VDC: 6W
Duty: Continuous at 85 to 105% of rated voltage
Coil Type: Class H. Molded with three-pins for
electrical connection or optional electrical plug-in
connector.
Enclosure Classification:
NEMA 4, per DIN 40050 – IP 65
Connector Plug: Cable grip for cables 1/4" to
5/16" (6 to 8 mm) in diameter.
Electrical Connections –
KD Series Operators: Furnished with 1/2"
conduit connector molded into coil, leads
are 18" long
KQ Series Operators: Furnished without a
connector
Override: Manual, locking or nonlocking.
Pilot Supply: Internal - standard, External - optional
External Pilot Supply Port: 1/8" PTF (ISO G
Optional).
Minimum Electrical Signal Duration: Solenoid
operated 2-position detented or nondetented
valves can be shifted with a momentary electrical
signal. Minimum signal duration is 13 milliseconds
for single solenoid operated spring return valves.
Double solenoid operated valves minimum signal
duration is 20 milliseconds.
Optional electrical connectors for KQx Series
operators conform to DIN43650 Form A for Three-
Pin Electrical Connectors.
Electrical spades on the KQx Series operator coil
are 3-pin with 18 mm spacing.
CSA Certified Valves
KDx and KQx Series solenoid operators are CSA
Certified. Optional solenoid coil voltages,solenoid
cable grip electrical connectors and 1/2" NPT
conduit electrical connectors also qualify for CSA
Certification.
