Nugget 200 Spool Valves
VAL-10-24 Littleton, CO USA Phone: 303-794-2611 www.norgren.com
Min.
Operating
Position Operator Description Force lbs. (kg)
2-Position
KP0 Tappet, Nondetent
18.0
(8.2)
KR2 Lever Roller, Nondetent (Inline Only)
11.0
(5.0)
KR3 One-Way Trip Roller, Nondetent
11.0
(5.0)
KR4 Lever Roller, Nondetent
11.0
(5.0)
KR5 One-Way Trip Roller, Nondetent (Inline Only)
11.0
(5.0)
Mechanical Operators
Min.
Operating
Position Operator Description Force lbs. (kg)
2-Position
KB0 Palm Button - Black, Nondetent (Inline Only)
18.0
(8.2)
KB1 Palm Button - Red, Nondetent (Inline Only)
18.0
(8.2)
KB2 Palm Button - Green, Nondetent (Inline Only)
18.0
(8.2)
KB3 Palm Button - Black, Detent (Inline Only)
9.0
(4.1)
KB4 Palm Button - Red, Detent (Inline Only)
9.0
(4.1)
KB5 Palm Button - Green, Detent (Inline Only)
9.0
(4.1)
KF0 Foot Pedal, Nondetent
11.0
(5.0)
KK0 Knob - Black, Nondetent
18.0
(8.2)
KK1 Knob - Black, Detent
9.0
(4.1)
KL0 Lever, Nondetent (Inline Only)
9.0
(4.1)
KL1 Lever, 2-Position Detent (Inline Only)
7.0
(3.2)
KL5 Lever, Nondetent
9.0
(4.1)
KL6 Lever, 2-Position Detent
7.0
(3.2)
KT0 Treadle, Nondetent (Inline Only)
13.0
(5.9)
KT1 Treadle, 2-Position Detent (Inline Only)
9.0
(4.1)
3-Position
KB6 Palm Button - Black, Spring Centered
9.0
(4.1)
KK2 Knob - Black, Spring Centered
9.0
(4.1)
KK3 Knob - black, 3-Position Detent
9.0
(4.1)
KL2 Lever, Spring Centered (Inline Only)
7.0
(3.2)
KL3 Lever, 3-Position Detent (Inline Only)
7.0
(3.2)
KL7 Lever, Spring Centered
7.0
(3.2)
KL8 Lever, 3-Position Detent
7.0
(3.2)
KT2 Treadle, Spring Centered
9.0
(4.1)
Manual Operators
