Nugget 200 Spool Valves
Littleton, CO USA Phone: 303-794-2611 www.norgren.com VAL-10-21
Air Pilot Operated Stacking Valve
Pilot
Port Pressure Weight Repair
Description Symbol Type Size Body* Operator psig (bar) lbs. (kg) Kit
Single
1/4" K78DA00 KS6-KA2
35 - 150 .53
54237-56
Solenoid 5-Port/ (2.4 - 10.3) (.24)
Spring 2-Position
3/8" K78EA00 KS6-KA2
35 - 150 .53
54237-56 Return
(2.4 - 10.3) (.24)
5-Port/
1/4" K79DA00 KS6-KA2
35 - 150 .53
54237-56
2-Position (2.4 - 10.3) (.24)
Common
3/8" K79EA00 KS6-KA2
35 - 150 .53
54237-56 Inlet & Exh. (2.4 - 10.3) (.24)
Double
1/4" K78DA00 KA2-KA2
15 - 150 .53
54237-56
Solenoid 5-Port/ (1.0 - 10.3) (.24)
(Non-
2-Position
3/8" K78EA00 KA2-KA2
15 - 150 .53
54237-56 Detented) (1.0 - 10.3) (.24)
5-Port/ 1/4" K79DA00 KA2-KA2
15 - 150 .53
54237-56
2-Position (1.0 - 10.3) (.24)
Common
3/8" K79EA00 KA2-KA2
15 - 150 .53
54237-56 Inlet & Exh. (1.0 - 10.3) (.24)
Double 5-Port/ 1/4" K88DA00 KAC-KAC
45 - 150 .53
54237-56
Solenoid 3-Position (3.1 - 10.3) (.24)
(Non- All Ports
3/8" K88EA00 KAC-KAC
45 - 150 .53
54237-56 Detented Blocked (3.1 - 10.3) (.24)
Common
5-Port/ 1/4" K88DA05 KAC-KAC
45 - 150 .53
54237-57 Inlet-Port 1
3-Position (3.1 - 10.3) (.24)
Inlet Open
3/8" K88EA05 KAC-KAC
45 - 150 .53
54237-57
to Cylinder (3.1 - 10.3) (.24)
5-Port/ 1/4" K88DA06 KAC-KAC
45 - 150 .53
54237-58
3-Position (3.1 - 10.3) (.24)
Cyl Open
3/8" K88EA06 KAC-KAC
45 - 150 .53
54237-58
to Exhaust (3.1 - 10.3) (.24)
Double 5-Port/ 1/4" K89DA00 KAC-KAC
45 - 150 .53
54237-56
Solenoid 3-Position (3.1 - 10.3) (.24)
(Non- All Ports
3/8" K89EA00 KAC-KAC
45 - 150 .53
54237-56 Detented Blocked (3.1 - 10.3) (.24)
Common
5-Port/
1/4" K89DA05 KAC-KAC
45 - 150 .53
54237-57 Inlet &
3-Position (3.1 - 10.3) (.24)
Exhaust -
Inlet Open
3/8" K89EA05 KAC-KAC
45 - 150 .53
54237-57 Ports 1,3&5
to Cylinder (3.1 - 10.3) (.24)
5-Port/ 1/4" K89DA06 KAC-KAC
45 - 150 .53
54237-58
3-Position (3.1 - 10.3) (.24)
Cyl Open to
3/8" K89EA06 KAC-KAC
45 - 150 .53
54237-58
Exhaust (3.1 - 10.3) (.24)
Double
1/4" K78DA00 KAA-KAA
25 - 150 .53
54237-56
Solenoid 5-Port/ (1.7 - 10.3) (.24)
(Detented)
2-Position
3/8" K78EA00 KAA-KAA
25 - 150 .53
54237-56
(1.7 - 10.3) (.24)
5-Port/ 1/4" K79DA00 KAA-KAA
25 - 150 .53
54237-56
2-Position (1.7 - 10.3) (.24)
Common
3/8" K79EA00 KAA-KAA
25 - 150 .53
54237-56 Inlet & Exh (1.7 - 10.3) (.24)
12
2 4
3 1 5
14
2 4
1 5 3
14 12
2 4
1 5 3
14 12
2 4
1 5 3
14 12
2 4
1 5 3
14 12
2 4
1 5 3
14 12
2 4
1 5 3
14 12
2 4
3 1 5
14 12
12
2 4
3 1 5
14
* Standard valves are equipped with PTF threads, solenoid operators with locking overrides, internal pilot, 120V/60 Hz-110V/50 Hz coils and cable grip
connectors. Optional solenoid operators, coil voltages and electrical connectors can be ordered using the information on p. VAL-10-11/12.
Note: For ISO-G threads, insert “G” in the 5th position.
