8

DS578F3

CS8416

SWITCHING CHARACTERISTICS

(Inputs: Logic 0 = 0 V, Logic 1 = VL; C

L

= 20 pF)

Notes:

5. Typical RMS cycle-to-cycle jitter.
6. Duty cycle when clock is recovered from biphase encoded input.
7. Duty cycle when OMCK is switched over for output on RMCK.

Parameter

Symbol

Min

Typ

Max

Units

RST Pin Low Pulse Width

200

-

-

μS

PLL Clock Recovery Sample Rate Range

30

-

200

kHz

RMCK Output Jitter

(Note 5)

-

200

-

ps RMS

RMCK Output Duty-Cycle

(Note 6)
(Note 7)

45
50

50
55

55
65

%
%

RMCK/OMCK Maximum Frequency

-

-

50

MHz
