48 DS578F3
CS8416
Control4 Register (04h)
RUN = 1
RXD = 0
RX_SEL[2] = 0
RX_SEL[1:0] = RX_SEL[1:0] pins.
TX_SEL[2] = 0
TX_SEL[1:0] = TX_SEL[1:0] pins.
Serial Audio Data Format Register (05h)
SOMS = set by RCBL pull-up/down after reset.
bits[6:0] = Set by pull-up/down on AUDIO & C after reset. See Table 5 for bit settings.
Receiver Error Mask register (06h)
QCRCM = 0
CRCM = 0
UNLOCKM = 1
CONFM = 1
BIPM = 1
PARM = 1
VM = set by NV/RERR pull-up/down after reset.
Registers 07h through 7Fh do not have Hardware Mode equivalent settings.
Serial Format Select [1:0] SOSF SORES[1:0] SOJUST SODEL SOSPOL SOLRPOL
00 (Left-Justified 24-bit) 0 00 0 0 0 0
01(I²S 24 bit) 0 00 0 1 0 1
10 (Right-Justified 24-bit) 0 00 1 0 0 0
11 (Direct AES3) 0 11 0 0 0 0
Table 5. Hardware Mode Serial Audio Format Select
