CS5490

DS982F3

13

SWITCHING CHARACTERISTICS

• Min / Max characteristics and specifications are guaranteed over all

Recommended Operating Conditions

.

• Typical characteristics and specifications are measured at nominal supply voltages and T

A

= 25°C.

• VDDA = +3.3V ±10%; GNDA = 0V. All voltages with respect to 0V.
• Logic Levels: Logic 0 = 0V, Logic 1 = VDDA.

Notes:

13.

Specified using 10% and 90% points on waveform of interest. Output loaded with 50pF.

14.

Oscillator start-up time varies with crystal parameters. This specification does not apply when using an external clock source.

Parameter

Symbol Min Typ

Max

Unit

Rise Times

DO

(Note 13)

Any Digital Output Except DO

t

rise

-
-

-

50

1.0

-

µs
ns

Fall Times

DO

(Note 13)

Any Digital Output Except DO

t

fall

-
-

-

50

1.0

-

µs
ns

Start-up

Oscillator Start-up Time

XTAL = 4.096 MHz (Note 14)

t

ost

-

60

-

ms
