DS680F2 65
CS42L52
3/1/13
6.29 Limiter Control 1, Min/Max Thresholds (Address 27h)
6.29.1 Limiter Maximum Threshold
Sets the maximum level, below full scale, at which to limit and attenuate the output signal at the attack
rate (LIMARATE -
“Limiter Release Rate” on page 66 ).
Note: Bass, Treble, and digital gain settings that boost the signal beyond the maximum threshold may
trigger an attack.
6.29.2 Limiter Cushion Threshold
Sets the minimum level at which to disengage the Limiter’s attenuation at the release rate (LIMRRATE -
“Limiter Release Rate” on page 66 ) until levels lie between the LMAX and CUSH thresholds.
Note: This setting is usually set slightly below the LMAX threshold.
6.29.3 Limiter Soft Ramp Disable
Configures an override of the digital soft ramp setting.
Note: This bit is ignored when the DIGZC ( “Digital Zero Cross” on page 53 ) is enabled.
7 6 5 4 3 2 1 0
LMAX2 LMAX1 LMAX0 CUSH2 CUSH1 CUSH0 LIMSRDIS LIMZCDIS
LMAX[2:0] Threshold Setting
000 0 dB
001 -3 dB
010 -6 dB
011 -9 dB
100 -12 dB
101 -18 dB
110 -24 dB
111 -30 dB
Application: “Limiter” on page 30
CUSH[2:0] Threshold Setting
000 0 dB
001 -3 dB
010 -6 dB
011 -9 dB
100 -12 dB
101 -18 dB
110 -24 dB
111 -30 dB
Application: “Limiter” on page 30
LIMSRDIS Limiter Soft Ramp Disable
0 OFF; Limiter Attack Rate is dictated by the DIGSFT ( “Digital Soft Ramp” on page 53 ) setting
1 ON; Limiter volume changes take effect in one step, regardless of the DIGSFT setting.
Application: “Limiter” on page 30
