3. CHARACTERISTIC AND SPECIFICATIONS
RECOMMENDED OPERATING CONDITIONS
AGND=DGND=0 V, All voltages with respect to ground.
ABSOLUTE MAXIMUM RATINGS
AGND = DGND = 0 V; All voltages with respect to ground.
WARNING: Operation at or beyond these limits may result in permanent damage to the device. Normal operation
is not guaranteed at these extremes.
Notes:
1.
Any pin except supplies. Transient currents of up to ±100 mA on the analog input pins will not cause
SCR latch-up.
2.
The maximum over/under voltage is limited by the input current.
Parameters
Symbol Min Max
Units
DC Power Supply
Analog
VA
1.65
2.63
V
Headphone Amplifier
+VHP
1.65
2.63
V
Speaker Amplifier
VP
1.60
5.25
V
Digital
VD
1.65
2.63
V
Serial/Control Port Interface
VL
1.65
3.47
V
Ambient Temperature
Commercial - CNZ
T
A
-40
+85
C
Parameters
Symbol
Min
Max
Units
DC Power Supply
Analog
Speaker
Digital
Serial/Control Port Interface
VA, VHP
VP
VD
VL
-0.3
-0.3
-0.3
-0.3
3.0
6.0
3.0
4.0
V
V
V
V
Input Current
I
in
-
±10
mA
External Voltage Applied to Analog Input
VIN
AGND-0.3
VA+0.3
V
External Voltage Applied to Analog Output
VIN
-VHP - 0.3
+VHP + 0.3
V
External Voltage Applied to Digital Input
V
IND
-0.3
VL+ 0.3
V
Ambient Operating Temperature
(power applied)
T
A
-50
+115
°C
Storage Temperature
T
stg
-65
+150
°C
