44 DS680F2
CS42L52
3/1/13
6.4 Power Control 3 (Address 04h)
6.4.1 Headphone Power Control
Configures how the SPKR/HP pin, 31, controls the power for the headphone amplifier.
6.4.2 Speaker Power Control
Configures how the SPKR/HP pin, 31, controls the power for the speaker amplifier.
6.5 Clocking Control (Address 05h)
6.5.1 Auto-Detect
Configures the auto-detect circuitry for detecting the speed mode of the CODEC when operating as a
slave.
Notes:
1. The SPEED[1:0] bits are ignored and speed is determined by the MCLK/LRCK ratio.
2. Certain sample and MCLK frequencies require setting the SPEED[1:0] bits, the 32k_GROUP bit
(
“32kHz Sample Rate Group” on page 45 ) and/or the VIDEOCLK bit ( “27 MHz Video Clock” on
page 45 ) and RATIO[1:0] bits ( “Internal MCLK/LRCK Ratio” on page 45 ). Low sample rates may also
affect dynamic range performance in the typical audio band. Refer to the referenced application for
more information.
7 6 5 4 3 2 1 0
PDN_HPB1 PDN_HPB0 PDN_HPA1 PDN_HPA0 PDN_SPKB1 PDN_SPKB0 PDN_SPKA1 PDN_SPKA0
PDN_HPx[1:0] Headphone Status
00
Headphone channel is ON when the SPKR/HP pin, 31, is LO.
Headphone channel is OFF when the SPKR/HP pin, 31, is HI.
01
Headphone channel is ON when the SPKR/HP pin, 31, is HI.
Headphone channel is OFF when the SPKR/HP pin, 31, is LO.
10 Headphone channel is always ON.
11 Headphone channel is always OFF.
PDN_SPKx[1:0] Speaker Status
00
Speaker channel is ON when the SPKR/HP pin, 31, is LO.
Speaker channel is OFF when the SPKR/HP pin, 31, is HI.
01
Speaker channel is ON when the SPKR/HP pin, 31, is HI.
Speaker channel is OFF when the SPKR/HP pin, 31, is LO.
10 Speaker channel is always ON.
11 Speaker channel is always OFF.
7 6 5 4 3 2 1 0
AUTO SPEED1 SPEED0 32k_GROUP VIDEOCLK RATIO1 RATIO0 MCLKDIV2
AUTO Auto-detection of Speed Mode
0 Disabled
1 Enabled
Application: “Serial Port Clocking” on page 33
