DS680F2 51
CS42L52
3/1/13
6.11.4 Invert ADC Signal Polarity
Configures the polarity of the ADC signal.
6.11.5 ADC Mute
Configures a digital mute on ADC channel x.
Note: When the ADCxMUTE bit is enabled, the PGA will automatically apply 6 dB of attenuation.
6.12 Playback Control 1 (Address 0Dh)
6.12.1 Headphone Analog Gain
Selects the gain multiplier for the headphone/line outputs.
Note: Refer to “Line Output Voltage Level Characteristics” on page 19 and “Headphone Output Power
Characteristics” on page 18 .
6.12.2 Playback Volume Setting B=A
Configures independent or ganged volume control of all playback channels.
INV_ADCx ADC Signal Polarity
0 Not Inverted
1 Inverted
ADCxMUTE ADC Mute
0 Disabled
1 Enabled
7 6 5 4 3 2 1 0
HPGAIN2 HPGAIN1 HPGAIN0 PLYBCKB=A INV_PCMB INV_PCMA MSTBMUTE MSTAMUTE
HPGAIN[2:0] Headphone/Line Gain Setting (G)
000 0.3959
001 0.4571
010 0.5111
011 0.6047
100 0.7099
101 0.8399
110 1.000
111 1.1430
PLYBCKB=A Single Volume Control Affected Volume Controls
0 Disabled HPxMUTE ( “Playback Control 2 (Address 0Fh)” on page 54 ),
AMIXxVOL[7:0] ( “ADC Mixer Channel x Volume” on page 58 ),
PMIXxVOL[7:0] ( “PCM Mixer Channel x Volume” on page 58 ),
MSTxVOL[7:0] ( “Master Volume Control” on page 63 ),
HPxVOL[7:0] ( “Headphone Volume Control” on page 63 )
1 Enabled
