Cirrus Logic CS42L52 - Manual (Page 63)

DS680F2 63
CS42L52
3/1/13
6.24.2 Bass Gain
Sets the gain of the bass shelving filter.
6.25 Master Volume Control: MSTA (Address 20h) and MSTB (Address 21h)
6.25.1 Master Volume Control
Sets the volume of the signal out the DSP.
6.26 Headphone Volume Control: HPA (Address 22h) and HPB (Address 23h)
6.26.1 Headphone Volume Control
Sets the volume of the signal out the DAC.
TREB[3:0] Gain Setting
0000 +12.0 dB
··· ···
0111 +1.5 dB
1000 0 dB
1001 -1.5 dB
··· ···
1111 -10.5 dB
Step Size: 1.5 dB
7 6 5 4 3 2 1 0
MSTxVOL7 MSTxVOL6 MSTxVOL5 MSTxVOL4 MSTxVOL3 MSTxVOL2 MSTxVOL1 MSTxVOL0
MSTxVOL[7:0] Master Volume
0001 1000 +12.0 dB
··· ···
0000 0000 0 dB
1111 1111 -0.5 dB
1111 1110 -1.0 dB
··· ···
0011 0100 -102 dB
··· ···
0001 1001 -102 dB
Step Size: 0.5 dB
7 6 5 4 3 2 1 0
HPxVOL7 HPxVOL6 HPxVOL5 HPxVOL4 HPxVOL3 HPxVOL2 HPxVOL1 HPxVOL0
HPxVOL[7:0] Headphone Volume
0000 0000 0 dB
1111 1111 -0.5 dB
1111 1110 -1.0 dB
··· ···
0011 0100 -96.0 dB
··· ···
0000 0001 Muted
Step Size: 0.5 dB
