58
DS680F2
CS42L52
3/1/13
6.19
ADCx Mixer Volume: ADCA (Address 18h) and ADCB (Address 19h)
6.19.1
ADC Mixer Channel x Mute
Configures a digital mute on the ADC mix in the DSP.
6.19.2
ADC Mixer Channel x Volume
Sets the volume/gain of the ADC mix in the DSP.
6.20
PCMx Mixer Volume: PCMA (Address 1Ah) and PCMB (Address 1Bh)
6.20.1
PCM Mixer Channel x Mute
Configures a digital mute on the PCM mix from the serial data input (SDIN) to the DSP.
6.20.2
PCM Mixer Channel x Volume
Sets the volume/gain of the PCM mix from the serial data input (SDIN) to the DSP.
7
6
5
4
3
2
1
0
AMIXxMUTE
AMIXxVOL6
AMIXxVOL5
AMIXxVOL4
AMIXxVOL3
AMIXxVOL2
AMIXxVOL1
AMIXxVOL0
AMIXxMUTE
ADC Mixer Mute
0
Disabled
1
Enabled
AMIXxVOL[6:0]
Volume
001 1000
+12.0 dB
...
...
000 0001
+0.5 dB
000 0000
0 dB
111 1111
-0.5 dB
...
...
001 1001
-51.5 dB
Step Size:
0.5 dB
7
6
5
4
3
2
1
0
PMIXxMUTE
PMIXxVOL6
PMIXxVOL5
PMIXxVOL4
PMIXxVOL3
PMIXxVOL2
PMIXxVOL1
PMIXxVOL0
PMIXxMUTE
PCM Mixer Mute
0
Disabled
1
Enabled
PMIXxVOL[6:0]
Volume
001 1000
+12.0 dB
...
...
000 0001
+0.5 dB
000 0000
0 dB
111 1111
-0.5 dB
...
...
001 1001
-51.5 dB
Step Size:
0.5 dB
