Page 16
16
DS680F2
CS42L52
3/1/13
8.
. R
L
and C
L
reflect the recommended minimum resistance and maximum capacitance re-
quired for the internal op-amp's stability and signal integrity. In this circuit topology, C
L
will effectively
move the band-limiting pole of the amp in the output stage. Increasing this value beyond the recom-
mended 150 pF can cause the internal op-amp to become unstable.
ANALOG PASSTHROUGH CHARACTERISTICS
Test Conditions (unless otherwise specified): Input sine wave (relative to full-scale): 1 kHz through passive input filter; PGA and
HP/Line Gain = 0 dB; All Supplies = VA; T
A
= +25
C; Sample Frequency = 48 kHz; Measurement Bandwidth is 20 Hz to 20 kHz;
“Required Initialization Settings” on page 37
written on power up.
VA = 2.5 V
VA = 1.8 V
Parameters Min
Typ
Max
Min
Typ
Max
Unit
Analog In to HP/Line Amp (ADC is powered down)
R
L
= 10 k
Dynamic Range
A-weighted
unweighted
-
-
-96
-93
-
-
-
-
-94
-91
-
-
dB
dB
Total Harmonic Distortion + Noise
-1 dBFS
-20 dBFS
-60 dBFS
-
-
-
-70
-73
-33
-
-
-
-
-
-
-70
-71
-31
-
-
-
dB
dB
dB
Full-scale Input Voltage
-
0.91•VA
-
-
0.91•VA
-
Vpp
Full-scale Output Voltage
-
0.84•VA
-
-
0.84•VA
-
Vpp
Passband Ripple
-
0/-0.3
-
-
0/-0.3
-
dB
R
L
= 16
Dynamic Range
A-weighted
unweighted
-
-
-96
-93
-
-
-
-
-94
-91
-
-
dB
dB
Total Harmonic Distortion + Noise
-1 dBFS
-20 dBFS
-60 dBFS
-
-
-
-70
-73
-33
-
-
-
-
-
-
-70
-71
-31
-
-
-
dB
dB
dB
Full-scale Input Voltage
-
0.91•VA
-
-
0.91•VA
-
Vpp
Full-scale Output Voltage
-
0.84•VA
-
-
0.84•VA
-
Vpp
Output Power
-
32
-
-
17
-
mW
Passband Ripple
-
0/-0.3
-
-
0/-0.3
-
dB
