Cirrus Logic CS42L52 - Manual (Page 41)

DS680F2 41
CS42L52
3/1/13
1Bh PCMMIXB Vol PMIXBMUTE PMIXBVOL6 PMIXBVOL5 PMIXBVOL4 PMIXBVOL3 PMIXBVOL2 PMIXBVOL1 PMIXBVOL0
p 58 0 0 0 0 0 0 0 0
1Ch BEEP Freq,
On Time
FREQ3 FREQ2 FREQ1 FREQ0 ONTIME3 ONTIME2 ONTIME1 ONTIME0
p 59 0 0 0 0 0 0 0 0
1Dh BEEP Vol,
Off Time
OFFTIME2 OFFTIME1 OFFTIME0 BPVOL4 BPVOL3 BPVOL2 BPVOL1 BPVOL0
p 60 0 0 0 0 0 0 0 0
1Eh BEEP,
Tone Cfg.
BEEP1 BEEP0 BEEPMIXDIS TREB_CF1 TREB_CF0 BASS_CF1 BASS_CF0 TC_EN
p 61 0 0 0 0 0 0 0 0
1Fh Tone Ctl TREB3 TREB2 TREB1 TREB0 BASS3 BASS2 BASS1 BASS0
p 62 1 0 0 0 1 0 0 0
20h Master A Vol MSTAVOL7 MSTAVOL6 MSTAVOL5 MSTAVOL4 MSTAVOL3 MSTAVOL2 MSTAVOL1 MSTAVOL0
p 63 0 0 0 0 0 0 0 0
21h Master B Vol MSTBVOL7 MSTBVOL6 MSTBVOL5 MSTBVOL4 MSTBVOL3 MSTBVOL2 MSTBVOL1 MSTBVOL0
p 63 0 0 0 0 0 0 0 0
22h Headphone A
Volume
HPAVOL7 HPAVOL6 HPAVOL5 HPAVOL4 HPAVOL3 HPAVOL2 HPAVOL1 HPAVOL0
p 63 0 0 0 0 0 0 0 0
23h Headphone B
Volume
HPBVOL7 HPBVOL6 HPBVOL5 HPBVOL4 HPBVOL3 HPBVOL2 HPBVOL1 HPBVOL0
p 63 0 0 0 0 0 0 0 0
24h Speaker A
Volume
SPKAVOL7 SPKAVOL6 SPKAVOL5 SPKAVOL4 SPKAVOL3 SPKAVOL2 SPKAVOL1 SPKAVOL0
p 64 0 0 0 0 0 0 0 0
25h Speaker B
Volume
SPKBVOL7 SPKBVOL6 SPKBVOL5 SPKBVOL4 SPKBVOL3 SPKBVOL2 SPKBVOL1 SPKBVOL0
p 64 0 0 0 0 0 0 0 0
26h Channel Mixer
and Swap
PCMASWP1 PCMASWP0 PCMBSWP1 PCMBSWP0 ADCASWP1 ADCASWP0 ADCBSWP1 ADCBSWP0
p 64 0 0 0 0 0 0 0 0
27h Limit Ctl 1,
Thresholds
LMAX2 LMAX1 LMAX0 CUSH2 CUSH1 CUSH0 LIMSRDIS LIMZCDIS
p 65 0 0 0 0 0 0 0 0
28h Limit Ctl 2,
Release Rate
LIMIT LIMIT_ALL LIMRRATE5 LIMRRATE4 LIMRRATE3 LIMRRATE2 LIMRRATE1 LIMRRATE0
p 66 0 1 1 1 1 1 1 1
29h Limiter Attack
Rate
Reserved Reserved LIMARATE5 LIMARATE4 LIMARATE3 LIMARATE2 LIMARATE1 LIMARATE0
p 67 1 1 0 0 0 0 0 0
2Ah ALC Ctl 1,
Attack Rate
ALCB ALCA ALCARATE5 AALCRATE4 ALCARATE3 ALCARATE2 ALCARATE1 ALCARATE0
p 67 0 0 0 0 0 0 0 0
2Bh ALC Release
Rate
Reserved Reserved ALCRRATE5 ALCRRATE4 ALCRRATE3 ALCRRATE2 ALCRRATE1 ALCRRATE0
p 68 0 0 1 1 1 1 1 1
2Ch ALC Thresh-
olds
ALCMAX2 ALCMAX1 ALCMAX0 ALCMIN2 ALCMIN1 ALCMIN0 Reserved Reserved
p 68 0 0 0 0 0 0 0 0
2Dh Noise Gate Ctl NGALL NG NGBOOST THRESH2 THRESH1 THRESH0 NGDELAY1 NGDELAY0
p 69 0 0 0 0 0 0 0 0
2Eh Overflow and
Clock Status
Reserved SPCLKERR DSPBOVFL DSPAOVFL PCMAOVFL PCMBOVFL ADCAOVFL ADCBOVFL
p 70 0 0 0 0 0 0 0 0
2Fh Battery Com-
pensation
BATTCMP VPMONITOR Reserved Reserved VPREF3 VPREF2 VPREF1 VPREF0
p 71 0 0 0 0 0 0 0 0
30h VP Battery
Level
VPLVL7 VPLVL6 VPLVL5 VPLVL4 VPLVL3 VPLVL2 VPLVL1 VPLVL0
p 72 0 0 0 0 0 0 0 0
31h Speaker Status Reserved Reserved SPKASHRT SPKBSHRT SPKR/HP Reserved Reserved Reserved
p 72 0 0 0 0 0 0 0 0
32h Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
0 0 1 1 1 0 1 1
33h Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
0 0 0 0 0 0 0 0
34h Charge Pump
Frequency
CHGFREQ3 CHGFREQ2 CHGFREQ1 CHGFREQ0 Reserved Reserved Reserved Reserved
p 73 0 1 0 1 1 1 1 1
Adr. Function 7 6 5 4 3 2 1 0
