Page 57: 1 sdin1 mask 2, Cs4234
DS899F1
57
CS4234
6.7
Serial Data Input 1 Mask 1 (Address 0Ah)
6.7.1
SDIN1 Mask 1
This field determines what data is masked from the max detect and envelope tracking blocks in the DAC5
data path.
6.8
Serial Data Input 1 Mask 2 (Address 0Bh)
6.8.1
SDIN1 Mask 2
This field determines what data is masked from the max detect and envelope tracking blocks in the DAC5
data path.
7
6
5
4
3
2
1
0
SDIN1 MASK 1[7:0]
SDIN1 MASK 1
Unmasked Data (in addition to any other data that is unmasked by its respective mask bits):
11111111
All Data is Masked.
0xxxxxxx
Slot 1 of SDIN1.
x0xxxxxx
Slot 2 of SDIN1.
xx0xxxxx
Slot 3 of SDIN1.
xxx0xxxx
Slot 4 of SDIN1.
xxxx0xxx
Slot 5 of SDIN1.
xxxxx0xx
Slot 6 of SDIN1.
xxxxxx0x
Slot 7 of SDIN1.
xxxxxxx0
Slot 8 of SDIN1.
7
6
5
4
3
2
1
0
SDIN1 MASK 2[7:0]
SDIN1 MASK 2
Unmasked Data (in addition to whatever other data is unmasked by its respective mask bits):
11111111
All Data is masked.
0xxxxxxx
Slot 9 of SDIN1.
x0xxxxxx
Slot 10 of SDIN1.
xx0xxxxx
Slot 11 of SDIN1.
xxx0xxxx
Slot 12 of SDIN1.
xxxx0xxx
Slot 13 of SDIN1.
xxxxx0xx
Slot 14 of SDIN1.
xxxxxx0x
Slot 15 of SDIN1.
xxxxxxx0
Slot 16 of SDIN1.
