4. Parametrizing blocks
4−16
Festo P.BE−SFC−DC−PB−S7−E N en 0604NH
4.5 Fault information
A distinction is always made between two types of faults:
block faults and transmission faults.
Block faults (e.g. incorrect logic address, incorrect hardware
configuration, etc.) are caused by the relevant system funcĆ
tion blocks used SFC14/SFC15, SFC58/SFC59, SFB52/SFB53
or SFC24 and shown at the output RET_VALUE. The fault code
can be found in the STEP 7 help. If a block fault occurs, the
block will be exited with the ENO bit = 0.
Transmission faults arise as a result of incorrect parameter
data (e.g. non−existent PNU, incorrect parameter length when
writing, non−existent subindex, etc.).
Transmission faults are shown with the bit Fault.
With the aid of the value of Value_RD the fault can be evaluĆ
ated accordingly Tab. 4/10.
Fault numbers Description
0 0x00 Non−permitted PNU The parameter does not exist.
1 0x01 Parameter value cannot be modified (read only)
(2) 0x02 ć (reserved ć lower or upper limit value exceeded) 1)
3 0x03 Faulty subindex
4 0x04 No array
5 0x05 Incorrect data type
(6) 0x06 ć (reserved ć setting not permitted ć can only be reset) 1)
(7) 0x07 ć (reserved ć describing element cannot be modified) 1)
(8) 0x08 ć (reserved ć PPO−Write requested in IR does not exist) 1)
9 0x09 Description data do not exist
(10) 0x10 ć (reserved ć access group incorrect) 1)
11 0x0A No control sovereignty
(12) 0x0B ć (reserved ć password incorrect) 1)
1) These fault numbers are not used
