Stop record with Halt and delete remaining path

Record_No

Ack_Start

MC

Actual_Record_No

N − 1

N

N + 1

N − 1

N

1

0

1

0

1

0

1

0

1

0

1

0

Drive_is_moving

Halt

N + 1

1

0

Start_
Positioning_Task

Clear_remaining_
Position

1

0

1

0

Halt_Not_Active

1

2

1

Stop record

2

Delete remaining path

Fig. A/5:

Sequence diagram for stop record with Halt and delete remaining path
