2. Installation and project overwiev
2−16
Festo P.BE−SFC−DC−PB−S7−E N en 0604NH
2.3.5 Folder PRM_UP−DOWNLOAD" ć transmitting several parameters
The most important blocks in the folder UP−DOWNLOAD" for
transmitting several parameters are listed in Tab. 2/6.
Additional blocks, e.g. for fault treatment or data blocks, etc.
are not listed.
Block Name Purpose Description Access Function
OB1 Main Cyclic program
access Main program routine FB1 Example
project
FB1 UP−DOWN Parametrizing Function block contains
examples of routines for
exchanging parameter sets FB20,
FB23 Example
project
FB20 PRM_FPC Parametrizing
(DPV0) FB for parametrizing via
FPC SFC14/15 Festo control
block
FB23 PRM_DB−FILE Parametrizing
(DPV0/DPV1) FB controls the upload/
download of parameter
sets from a global DB via
one of the three transĆ
mission paths SFC24 Festo control
block
DB91 GV−PRM Parametrizing Contains the global control
variables for parametrizing ć Example
project
DIAGNOSTIC BUFFER Parametrizing Variable table for reading
out the diagn. memory ć Example
project
PARAMETERIZE−DRIVE Parametrizing Variable table for
parametrizing ć Example
project
Tab. 2/7: Overview of the most important blocks of the folder PRM_DPV1_SFC"
Block FB1 is implemented in OB1. Block FB23 for transmitting
parameter sets as well as block FB20 for parametrizing the
SFC−DC via the Festo Parameter Channel (DPV0) are implemĆ
ented in FB1. This is also possible via the blocks FB21 or
FB22.
The global variables for parametrizing are saved in DB91.
With the aid of the variable table PARAMETERIZE−DRIVE the
controller can be parametrized via PROFIBUS. The diagnostic
memory can be read out with the variable table DIAGNOSTIC
BUFFER.
