4. Parametrizing blocks
4−13
Festo P.BE−SFC−DC−PB−S7−E N en 0604NH
4.4.2 Input parameters
Parameters DeclaĆ
ration Data
type Description
Start_RxTx INPUT BOOL Start transmission
Rx_Tx INPUT BOOL Read DB / write DB
DB_Source INPUT INT Source DB
DB_Target INPUT INT Target DB
_Done_RD_WR INPUT BOOL Transmission of individual parameters is concluded
_Fault_RD_WR INPUT BOOL Faults in the transmission of individual parameters
_Length_RD INPUT INT Length of the read parameter in BYTE
_Value_RD INPUT DWORD Parameter value of the current parameter when reading
Tab. 4/7: Input parameter PRM_DB−FILE
