Parts Listings and Cross-Sectionals
Table 5: Parts list with materials of construction for ball bearing arrangement
The materials in this table are typical. Refer to the order documentation for the actual materials furnished.
Item Part name Quantity Construction - API designation
per
S-6 S-8N C-6 A-8N D-1
pump
100 Casing 1 Carbon steel 12% chrome 316L SS Duplex 2
101/101M Impeller Varies 12% chrome 316L SS 12% chrome 316L SS Duplex 2
109A Thrust bearing end cover, out- 1 Carbon steel
board
112A Ball bearing, thrust 1 Steel
114 Oil ring 2 Brass
117 Sleeve bearing 2 Babbitted tin / steel
122 Shaft 1 17-4PH Nitronic 50 17-4PH Nitronic 50 Duplex
128 Throttle bushing sleeve 1 Nitronic 60 H.F. duplex 1
129 Throttle bushing 1 410 SS hard- 316L SS 410 SS hard- 316L SS H.F. duplex 1
ened ened
134 Housing, bearing - radial and 2 Carbon steel
thrust
136/382 Bearing locknut and lockwasher 1 Steel
144 Stage ring Varies 410 SS hard- 316L SS 410 SS hard- 316L SS H.F. duplex 1
ened ened
155 Center bushing 1 410 SS hard- 316L SS 410 SS hard- 316L SS H.F. duplex 1
ened ened
160 Bearing end cover, radial (in- 3 Carbon steel
board and outboard) and thrust
(inboard)
164/164A/ Wear rings, casing Varies 410 SS hard- 316L SS 410 SS hard- 316L SS H.F. duplex 1
164B ened ened
168 Bearing, radial 1 Steel
178 Key, impeller Varies 316 SS 316 SS 410 SS 316 SS Duplex
202, 202A, Wear rings, impeller Varies 17-4PH Nitronic 60 17-4PH Nitronic 60 H.F. duplex 1
202B, 203
205 Center sleeve 1 Nitronic 60 H.F. duplex 1
217 Bearing spacer 1 Carbon steel
324 Oil ring sleeve, radial end 4 Carbon steel
332A Labyrinth seal, radial outboard 1 Bronze
333A Labyrinth seal, radial and thrust 2 Bronze
inboard
351 Gasket, casing 1 Garlock 3000
353 Stud, gland 8 4140
355 Nut, gland stud 8 4140
356A, Stud and nut, casing Varies 4140
356C,
356K, 425
360A Gasket, bearing end cover - radial 9 Vellumoid
and thrust
361F Snap ring Varies 316 SS
361H Locating ring Varies 316 SS Duplex
371C Capscrew, bearing housing end 16 Carbon steel
cover
371T/427J Stud and nut, bearing housing to 8 Carbon steel
casing/head
400 Coupling key 1 Carbon steel
443B Oil ring sleeve, thrust end 1 Carbon steel
520 Shaft nut 1 Carbon steel
1 Hardface with Colmonoy #6
2 ASTM A890 Grade 3A Duplex material will be supplied unless otherwise specified.
Model 3600, API 610 8th, 9th, 10th & 11th Editions (ISO 13709) Installation, Operation, and Maintenance Manual 99
