Parts Listings and Cross-Sectionals
Parts Listings and Cross-Sectionals
Parts list
Table 4: Parts list with materials of construction for sleeve/ball bearing arrangement
The materials in this table are typical. Refer to the order documentation for the actual materials furnished.
Item Part name Quantity Construction - API designation
per
S-6 S-8N C-6 A-8N D-1
pump
100 Casing 1 Carbon steel 12% chrome 316L SS Duplex 2
101/101M Impeller Varies 12% chrome 316L SS 12% chrome 316L SS Duplex 2
109A Thrust bearing end cover, out- 1 Carbon steel
board
112A Ball bearing, thrust 1 pair Steel
114 Oil ring, thrust bearing 1 Brass
117 Sleeve bearing 2 Babbitted tin / steel
122 Shaft 1 17-4PH Nitronic 50 17-4PH Nitronic 50 Duplex
128 Throttle bushing sleeve 1 Nitronic 60 H.F. duplex 1
129 Throttle bushing 1 410 SS hard- 316L SS 410 SS hard- 316L SS H.F. duplex 1
ened ened
134 Housing, bearing - radial 1 Carbon steel
134A Housing, bearing - thrust 1 Carbon steel
136/382 Bearing locknut and lockwasher 1 Steel
144 Stage ring Varies 410 SS hard- 316L SS 410 SS hard- 316L SS H.F. duplex 1
ened ened
155 Center bushing 1 410 SS hard- 316L SS 410 SS hard- 316L SS H.F. duplex 1
ened ened
164/164A/ Wear rings, casing Varies 410 SS hard- 316L SS 410 SS 316L SS H.F. duplex 1
164B ened
178 Key, impeller Varies 316 SS 316 SS 410 SS 316 SS Duplex
202, 202A, Wear rings, impeller Varies 17-4PH Nitronic 60 17-4PH Nitronic 60 H.F. duplex 1
202B, 203
205 Center sleeve 1 Nitronic 60 H.F. duplex 1
217 Bearing spacer 1 Carbon steel
323 Oil ring sleeve 4 Brass
332A Labyrinth seal, outboard 1 Bronze
333A Labyrinth seal, inboard 2 Bronze
351 Gasket, casing 1 Garlock 3000
353 Stud, gland 8 4140
355 Nut, gland stud 8 4140
356A, Stud and nut, casing Varies 4140
356C,
356K, 425
360A Gasket, bearing end cover 6 Vellumoid
361F Snap ring Varies 316 SS
361H Locating ring Varies 316 SS Duplex
371T/427J Stud and nut, bearing housing to 8 Carbon steel
casing
371C Capscrew, bearing housing end 4 Carbon steel
cover
400 Coupling key 1 Carbon steel
443B Thrust collar 1 Carbon steel
520 Shaft nut 1 Carbon steel
1 Hardface with Colmonoy #6
2 ASTM A890 Grade 3A Duplex material will be supplied unless otherwise specified.
