Magazine
s
lay-on roller arm
6.3 Removing Exposed Film
If only part of the film roll has been exposed and you intend
leaving a ‘short end‘ in the magazine, cut the film loop
squarely through a perforation.
The following steps should be carried out in
total darkness in a darkroom or changing tent!
• Open the take-up side door by flipping the locking
grip upwards and turning the grip counter-clock-wise.
• Lift up the door and remove it by pulling it to the left.
• Manually wind the film roll counter-clockwise until the
film tail comes free from the lower sprocket roller.
• Swing the lay-on roller arm a photo away from the
winding shaft until it locks in place.
• Pull the film roll upwards and off.
Note: When pulling the film roll off the shaft, grip the
roll firmly to prevent the middle of the film roll
from sagging down.
The film tail should never be pulled to tighten the
roll. This causes scratches and static discharging.
lower sprocket roller
