Work Light WL-3
• Screw the work light into the Accessory Rosette.
• Connect the plug to an “RS” socket.
• Bend the flexible arm, to bring the work light into the
desired position. The work light can be turned on and
off with the ring on the lamp head a photo . The
brightness of the work light can be adjusted with the
mechanical shutter.
HE-4
WL-3
Acce
ss
orie
s
Heated Eyecup HE-4 & HE-5
The heated eyecup prevents the eyepiece a photo from
misting-up, e.g. when filming outdoors in cold weather.
• Pull the normal eyecup off the eyepiece and replace it
with the heated eyecup.
• Connect the heated eyecup to the heated eyepiece
outlet with cable KC-63.
• Set the heating level with the toggle switch a photo :
“LO”: low heat output
“HI”: higher heat output.
If the camera and accessories are powered by
battery, switching off the eyecup during extended
breaks in filming will help conserve power.
switch
