3.4 Card with a Barcode Data Field Tutorial
The purpose of this Card Design element is to create a barcode.
3.4.1 Design a Card with a Barcode
Step Procedure
1 Select Barcode from the Barcode group.
2 Click the card design area. The Barcode Properties dialog displays.
3 Select the barcode type in the Type field under Barcode.
4 Click the pre-existing data field to link within Available or create a new field in Select Fields.
5 Click Add>>. The information entered within the data field during enrollment automatically
populates the barcode.
6 Click OK.
7 Position the item precisely on the card design area.
3.5 Card with a Magnetic Stripe Tutorial
The purpose of this tutorial is to add magnetic encoded data to a card.
3.5.1 Design a Card with a Magnetic Stripe
Step Procedure
1 Launch the Asure ID software.
2 Enter your userID and password in the entry fields.
3 Click Card Design.
4 Click Card Setup on the menu ribbon.
Select the Dual-Sided Card icon in the Layout group.
5 Select Magstripe in the Technology group. The Magstripe Properties are set for Type (ISO or
Non-ISO or Custom) and Options.
6 Drop data objects to the card design area based on the information to be encoded on the
magnetic stripe. Designate the objects as non-printable within the Properties window of the
object.
7 Select Magstripe in the Technology group to access Tracks 1, 2, and 3 (Properties).
8 Select fields to be added to each track of the magnetic stripe. The current field options are
displayed in the Available box.
Click Add to make the field active.
9
Click the Save icon .
Name the file and click OK to close the Save Template dialog.
