Assembly & Installation Instructions
A335
Apparatus Pendant 138815 Page 1 of 5
Hand-Forged, Vermont-Made Lighting and Accessories
154 Route 30 South, Castleton, Vermont 05735 28309
To Install Mounting Bracket to Ceiling (Figure 1)
Component Parts
A Mounting Bracket
B Anchor (3)
C #10 Screw (3)
1. Carefully unpack fixture and canopy from carton.
2. Unscrew barrel knobs to separate mounting bracket from canopy.
3. Position the mounting bracket (A) over the electrical box aligning ovals in bracket with mounting holes in
electrical box. Orient fixture to desired hanging position and mark the location of the anchors (B) on the ceiling.
Set the mounting bracket aside.
4. Drill 1/8” holes in the location marked on the ceiling. Place the tapered ends of the anchors (B) into the holes and
gently tap flush using a lightweight hammer.
5. Place mounting bracket (A) over electrical box. Using two machine screws (not provided) fasten the mounting
bracket (A) to the electric box. Thread the #10 screws (C) through the bracket and into the anchors (C) to secure
the bracket to the ceiling. Be careful not to over tighten or strip the anchors.
Note: A new electric box comes with screws. When replacing an existing fixture, retain screws for use with the
new fixture.
(continued)
CAUTION: FAILURE TO INSTALL THIS FIXTURE PROPERLY MAY RESULT IN SERIOUS PERSONAL
INJURY OR DEATH AND PROPERTY DAMAGE. We recommend installation by a licensed electrician.
This product must be installed in accordance with applicable installation code(s), by a person familiar with the
construction and operation of the product and the hazards involved.*
Caution: Do not exceed maximum wattage noted on fixture. Use only recommended bulbs with fixture.
(Figure 1)
