Quality of Service (QoS)
64
5. Type 3 to select Low Priority Queue Weighting. The following prompt
is displayed:
Enter new value [1 to 15] ->
6. Enter the new value and press .
You will be returned to the QoS Menu.
7. Type 4 to set the 802.1p frame TCI Threshold. The TCI Threshold will
determine if a tagged frame is sent to either a high priority queue or
low priority queue.
The following prompt will be displayed:
Enter new value [1 to 8] ->
8. Enter the new value and press .
You will be returned to the QoS Menu.
9. Type 5 to select Port Based QoS. The Port Based QoS Menu in Figure
24 is displayed.
Figure 24 Port Based QoS Menu
Port-based QoS will determine if an untagged frame is sent to
either a high priority queue or low priority queue based on the
port-based QoS configuration.
