Appendix A: Technical Specifications
80
AT-CV5001DC
Power Supply
Module
DC Input Current: 40-60 Vdc , 6 A, 140W
maximum
Dimensions (W x D x H) 21.5 cm x 18.8 cm x 6.5 cm
(8.45 in x 7.4 in x 2.55 in)
Weight: 1.7 kg (3.8 lb.)
Power Supply Module Fuse Specifications
This information is for service personnel only.
Caution
For continued protection against risk of fire, replace the fuses only
with fuses of the same type and rating.
Safety and Electromagnetic Emissions Certifications
EMI: FCC Class A, EN55022 Class A,
VCCI Class A, C-TICK, CE
Immunity: EN55024
Safety: UL60950-1 (
C
UL
US
), EN60950-1
(TUV), CAN/CSA C22.2 No.
60950-1
Laser: EN60825
MTBF: Chassis: 1,840,000 hrs.
AT-CV5001AC: 180,000 hrs.
AT-CV5001DC: 190,000 hrs.
Table 6. Power Supply Fuse Specifications
Designator
Power Supply
Module
Location Rating
F1 AT-CV5001DC
Module Module board.
Main input fuse. 125V, 10A
F2 AT-CV5001AC and
AT-CV5001DC
Modules Module board.
Fan fuse. 125V, 1.5A
