AT-CV5001 Media Converter Chassis Installation Guide
69
Removing or Replacing the AT-CV5001AC Power Supply
The AT-CV5001AC Power Supply is hot-swappable. You do not have to
power off the chassis to install a second power supply or to replace a
failed power supply in a chassis that has two power supplies.
There are two power supply slots. This procedure illustrates slot A. The
procedure is the same for slot B.
Note
The predecessor to the AT-CV5001 Chassis, the AT-CV5000
Chassis, had different power supply modules for the left and right
slots. This is not the case for the AT-CV5001AC Power Supply,
which can be installed in either power supply slot in the AT-CV5001
Chassis.
To remove or replace the AT-CV5001AC Power Supply, perform the
following procedure.
1. Disconnect the power cord from the power source.
2. Disconnect the power cord from the AT-CV5001AC Power Supply.
Figure 35. Removing the Power Cord from the AT-CV5001AC Power
Supply
A
AT-CV5001
AC
DISCONNECT ALL
POWER SUPPLIES & REFER TO MAN UAL BEFORE SE
RVICING .
100-240V
AC~
A
WARN ING This unit
might h ave more than one p
ower input
. To reduce
t
of electric shoc
k, disconnect all p
ower inputs bef
ore ser vicin o
1671
