4-Channel Isolated D/A Converter with Waveform Memory Module 9
34980A User’s Guide 193
34951A Simplified Schematics
The following schematic shows how the module is generally configured.
DAC 3
16 Bits
DAC 2
DAC 1
16 Bits
16 Bits
16 Bits
Channel 001
External Clock Out Enable
Clock Out
External Trigger Out Enable
Trigger Out
External Clock In/Out
External Trigger In/Out
Channel 002
Channel 003
Channel 004
Internal to the 34951A Module User-Supplied Connections
DAC 4
See the following diagram for the
configuration of the DAC channels.
