Table 1 -

Consumed / Produced Parameter Descriptions

Consumed Directed
Digital Data Words

Function

Affects

Word 1 (bits 1 to 16)

Voltage/Current Mode, Input Filter Control

All Analog Modules

Word 2 (bits 17 to 32)

Scale factor

All Analog Modules

Word 3 (bits 33 to 48)

Specifies whether SmartStix uses default
configuration or values from Word 4.

All Analog Modules

Word 4 (bits 49 to 64)

Sets digital inputs / heartbeat and life
expectancy time data.

All Analog Modules

Word 5 (bits 65 to 80)

Sets the default state of Analog outputs.

Modules with Analog Outputs

Produced Global
Digital Data Words

Function

Affects

Word 1 (bits 1 to 16)

Reserved

Word 2 (bits 17 to 32)

Reserved

Word 3 (bits 33 to 48)

Status bits and diagnostic data

All Analog Modules

Word 4 (bits 49 to 64)

Device class number and firmware identifier
sent by SmartStix module.

All Analog Modules

Function

Consumed Directed
Analog Data Words

HE550MIX977

HE550DAC207

Affects

Word 1

Output Channel 1 Data

Modules with Analog Outputs

Word 2

Output Channel 2 Data

Modules with Analog Outputs

Word 3

Output Channel 3 Data

Modules with Analog Outputs

Word 4

Output Channel 4 Data

Modules with Analog Outputs

Word 5

Output 1 Default Data

Output Channel 5 Data

Modules with Analog Outputs

Word 6

Output 2 Default Data

Output Channel 6 Data

Modules with Analog Outputs

Word 7

Output 3 Default Data

Output Channel 7 Data

Modules with Analog Outputs

Word 8

Output 4 Default Data

Output Channel 8 Data

Modules with Analog Outputs

Word 9

Not used

Output 1 Default Data

Modules with Analog Outputs

Word 10

Not used

Output 2 Default Data

Modules with Analog Outputs

Word 11

Not used

Output 3 Default Data

Modules with Analog Outputs

Word 12

Not used

Output 4 Default Data

Modules with Analog Outputs

Word 13

Not used

Output 5 Default Data

Modules with Analog Outputs

Word 14

Not used

Output 6 Default Data

Modules with Analog Outputs

Word 15

Not used

Output 7 Default Data

Modules with Analog Outputs

Word 16

Not used

Output 8 Default Data

Modules with Analog Outputs

Function

Produced Global
Analog Data Words

HE550MIX977

HE550ADC970

Affects

Word 1

Input Channel 1 Data

Modules with Analog Inputs

Word 2

Input Channel 2 Data

Modules with Analog Inputs

Word 3

Input Channel 3 Data

Modules with Analog Inputs

Word 4

Input Channel 4 Data

Modules with Analog Inputs

Word 5

Input Channel 5 Data

Modules with Analog Inputs

Word 6

Input Channel 6 Data

Modules with Analog Inputs

Word 7

Input Channel 7 Data

Modules with Analog Inputs

Word 8

Input Channel 8 Data

Modules with Analog Inputs

Word 9

Not used

Input Channel 9 Data

Modules with Analog Inputs

Word 10

Not used

Input Channel 10 Data

Modules with Analog Inputs

Word 11

Not used

Input Channel 11 Data

Modules with Analog Inputs

Word 12

Not used

Input Channel 12 Data

Modules with Analog Inputs

Note: Table 1 summarizes SmartStix I/O analog module consumed and produced data words. For

advanced users, refer to Section Three: Advanced Programming for explanations describing
consumed and produced words in detail.
