3.4
SmartStix I/O Module Produced (Transmitted) Global Data
Table 12 – Produced Global Digital Data Word 1
16-bit Word
8-bit High Byte 8-bit Low Byte
Low Word
Reserved.
Table 13 – Produced Global Digital Data Word 2
16-bit Word
8-bit High Byte 8-bit Low Byte
High Word
Reserved
Table 14 – Produced Global Digital Data Word 3
16-bit Word
8-bit High Byte 8-bit Low Byte
Module Fault Data Network Fault Data Configuration Status Data
PUP I/O ROM RAM LIFE ID DUP NAK SIT SHT SLT
SLT
CLT command status; matches CLT when command is complete
SHT CHT command status; matches CHT when command is complete
SIT CIT command status; matches CIT when command is complete
NAK
Network Acknowledge test failed; found no other Network devices
DUP Network Duplicate ID test failed; found another Network device with our Network ID
ID Network ID test failed; Network ID rotary switches illegally set to 00, FE or FF
LIFE Network Life Expectancy Time has expired; outputs are in default state
RAM
Module RAM test failed; found a RAM memory fault during power-up-self-test
ROM Module ROM test failed; found a ROM memory fault during power-up-self-test
I/O Module I/O test failed; found an I/O fault during power-up-self-test
PUP Module just powered up; using default configuration; outputs are Off
Table 15 – Produced Global Data Word 4
16-bit Word
8-bit High Byte 8-bit Low Byte
Firmware Revision Status Data Device Identification Status Data
0.00 to 2.55 = Version Number 0 to 255 = Device Class Number
Device Class Number
SmartStix I/O Module’s numeric product identifier (see Table 3).
Version Number SmartStix I/O Module’s numeric firmware identifier
3.5
Produced Global Data Power-Up Initialization
At power-up, a SmartStix I/O Module’s four Produced Global Data words are initialized as follows:
1. Zeros are loaded into Words 1 and 2.
2. Power-up-self-test result is loaded into Word 3; if tests passed, only PUP bit is On.
3. Module’s Device Class Number and Version Number are loaded into Word 4.
4. All four Produced Global Data words are transmitted to the CsCAN Network.
