6.2.22 PELCO D commands recognised
by the receiver
As well as recognising standard PELCO D commands
relating to joystick and lens movements, the receiver
is able to recognise and execute the following
extended PELCO D commands.
PELCO D
COMMAND
EXDTRX3 /
EXDTRX324
COMMAND
NOTE
Set Auxiliary Aux ON Recognise values
between 1 and 4
Clear Auxiliary Aux OFF Recognise values
between 1 and 4
Set Pattern Start Autopan Toggle --
Run Pattern Patrol Toggle --
Remote Reset Receiver Reset --
Go To Preset
“1÷40” Scan Recognise values
between 1 and 40
Set Preset “1÷40” Preset position Recognise values
between 1 and 40
Clear Preset
“1÷40” Reset of Preset
Single Position Recognise values
between 1 and 40
Set Preset “41” Starting Patrol
parameters
acquisition
(see example**) --
Set Preset “…” Patrol “Position
From” Recognise values
between 1 and 40
Set Preset “…” Patrol “ Position
To” Recognise values
between 1 and 40
Set Preset “…” Patrol “Pause” Recognise values
between 1 and 99
Set Preset “42” Patrol Start --
Set Preset “43” Patrol Stop --
Set Preset “44” Washer-Wiper* --
Set Preset “55”
Set Preset “66” Reset of all Preset
positions The two
commands
must be given in
sequence
Tab. 03 * With the following timing: in the first second, only
the Washer is activated, in the next two seconds the
Washer and Wiper are activated simultaneously, and
then during the last second the Washer is switched off
and just the Wiper is left on.
6.2.19 Use of the alarm contacts
The 4 alarm contacts of EXDTRX3 / EXDTRX324
receiver are associated with the first four preset
positions; as soon as the alarm is activated,
the positioning device and the lens adopt the
corresponding preset position; the last alarm
activated takes always priority. The EXDTRX3 /
EXDTRX324 can also receive an alarm command
even through theDCJ, DCT and DCTEL control
keyboard (which in turn receives it from the SM164B
and SM328B matrix); in such case the positioning
device and the lens move themselves into the preset
position n°1.
In order to use the alarm contacts it is necessary to
set the SW4 according to the following instructions:
• Dip 3 of SW4 set to the ON position: The alarm
contacts are activated;
• Dip 3 of SW4 set to the OFF position: The alarm
contacts are deactivated;
• Dip 4 of SW4 set to the ON position: The alarm
contacts are normally open;
• Dip 3 of SW4 set to the OFF position: The alarm
contacts are normally closed.
6.2.20 Operation mode of AUX4
• Switches: Dip 5 of SW4
Settings:
• Dip 5 of SW4 OFF: Normal operation;
• Dip 5 of SW4 ON: AUX4 is activated on alarm and
deactivated when the alarm signal stops.
6.2.21 Local keys for P&T motor
movement
The receiver has 4 local arrow-keys (on board) for
the P&T motor movement in the 4 directions (Up,
Down, Left, Right, Fig. 06, page 10). These keys are
very useful during P&T motor installation in order
to control the position of limit switches and/or the
right setting of the P&T motor. The arrow-keys have
total priority and, when pressed, they deactivate at
the moment the receiver remote use (by keyboards).
When the arrow-keys are released the receiver
functions are fully restored.
The combination of Up key and reset key is used to
carry out the auto-test ("6.2.18 Testing the receiver",
page 16).
