Operating and installation instructions
Thrust actuator ARI-PREMIO-Plus
4.4 Technical data
Type ARI-PREMIO
Thrust force kN 2,2 5,0 12,0 15,0
Stroke distance max. mm 50 65
Duty classification acc. to EN 60034-1/A11 S3 80% DC/ max. 1200 c/h S3 50% DC / max. 1200 c/h
Control speed mm/sec. 0.38 1.0 0.38 0.79 0.38
Motor voltage 230V - 50Hz / 60Hz 1) 230V - 50Hz
Power consumption W 24 37 94 112 133
For power consumption of other voltages and frequencies
refer to type plate or on request.
Enclosure EN 60529 IP 65
Max. permissible storage temperature -40 °C ... +85 °C
Max. permissible ambient temperature -20 °C ... +70 °C
Manual operating device Yes (rotating during operation) Yes (engageable)
Operation Optionally:·
3-point: 12 V DC/AC to 250 V DC/AC·
0 to 10 V DC load resistance 470 kohm resolution 10 bit·
4 to 20 mA DC load resistance 125 ohm resolution 10 bit
Switching current Max. 4 A triac output
Input for temperature sensor Sensor: PT1000
Max. cable cross section Supply voltage: 2.5 mm²
3-point input: 2.5 mm²
Control signals: 1.5 mm²
Mounting position Any. Exception: motor must not be suspended downwards
Gear lubricant
Klüber Isoflex Topas NB152
Molyduval
Valenzia H2
Weight kg 5,4 6,0 6,5 10,5
1) Control speed and power consumption are 20% higher at frequency of 60 Hz
Accessories
Type
ARI-PREMIO
Thrust force kN 2,2 5,0 12,0 15,0
Electronic position indicator Analogue output 4-20 mA, switchable to 0-10 V (invertable)
Relay board
- 2 intermediate positions, settable with a switch, changeover contact 230 V AC 6A/3A,
- 1 failure signal and 1 warning signal, changeover contacts 30V DC / 2A
Heating resistor 230 V 50/60 Hz 1) , 115 V 50/60 Hz 1) , 24 V 50/60 Hz 1) , 15 W
Other voltages/ frequencies
24V - 50/60Hz 1)
115V - 50/60Hz
1)
24V - 50Hz
24V - 60Hz 1)
115V - 50/
60Hz 1)
24V - 50Hz / 24V - 60Hz
1)
115V - 50Hz / 115V - 60Hz 1)
230V - 60Hz
1)
3~400V - 50Hz / 3~400V - 60Hz 1)
Integrated temperature-controller
dTRON 316
Three-step temperature-controller in microprocessor-technology.
Control range: -200°C to 850°C (resistance thermometer)
Voltage: 24V, 115V or 230V 50/60Hz
Compatible with resistance thermometers and thermocouples
(provided by customer), or standardized active current or voltage signals
Integrated tempertaure controller dTRON
316 / PROFIBUS-DP Controler incl. PROFIBUS-DP-interface and analogue input card, 24 V, 115 V or 230 V 50/
60 Hz. Controlling via bus line (must be supplied by the customer).
1) Control speed and power consumption are 20% higher at frequency of 60 Hz
