ANALOG Analog Output Parameters
DISPLAY PARAMETER USER SETTING
tYPE ANALOG TYPE
ASSIGN ANALOG ASSIGNMENT
ANALOG LO ANALOG LOW
ANALOG HI ANALOG HIGH
UPdAtE ANALOG UPDATE TIME
dISPLY
DISPLAY PARAMETERS
LINE 1 Line 1 Parameters
DISPLAY PARAMETER USER SETTING
Color Line 1 Display Color
d-LEV Display Level
d-Cont Display Contrast Level
SELECt Line 1 Display Value Select
INPUt LO
GrOSS S1
tArE S2
tOtAL S3
HI S4
OUtPUt
OUTPUT PARAMETERS
SEtPNt Setpoint Output Parameters
DISPLAY PARAMETER USER SETTING USER SETTING USER SETTING USER SETTING
SELECt SETPOINT SELECTION S1 S2 S3 S4
ASSIGN SETPOINT SOURCE
ACtION ACTION FOR SETPOINT
SEtPNt SETPOINT VALUE
bn-dEV SETPOINT BAND/DEVIATION VALUE
HYStEr HYSTERESIS FOR SETPOINT
t-ON ON TIME DELAY SETPOINT
t-OFF OFF TIME DELAY SETPOINT
LOGIC OUTPUT LOGIC
rESEt RESET ACTION
StndbY STANDYBY OPERATION
Annun OUTPUT ANNUNCIATOR LIGHT
Color CHANGE COLOR
PARAMETER VALUE CHART Programmer ________________ Date ________
PAX2S Meter# _____________ Security Code ________
INPUt
INPUT SETUP PARAMETERS
ANALOG
Analog Input Parameters
DISPLAY PARAMETER USER SETTING
rANgE INPUT RANGE
rAtE INPUT UPDATE RATE
dECPNt DECIMAL RESOLUTION
round ROUNDING INCREMENT
tArE DISPLAY TARE (OFFSET)
FILtEr DIGITAL FILTER
bANd DIGITAL FILTER BAND
POINtS SCALING POINTS
StYLE SCALING STYLE
INPUt 1 INPUT 1 SCALING VALUE
dISPLY 1 DISPLAY 1 VALUE
INPUt 2 INPUT 2 SCALING VALUE
dISPLY 2 DISPLAY 2 VALUE
INPUt 3 INPUT 3 SCALING VALUE
dISPLY 3 DISPLAY 3 VALUE
INPUt 4 INPUT 4 SCALING VALUE
dISPLY 4 DISPLAY 4 VALUE
INPUt 5 INPUT 5 SCALING VALUE
dISPLY 5 DISPLAY 5 VALUE
INPUt 6 INPUT 6 SCALING VALUE
dISPLY 6 DISPLAY 6 VALUE
INPUt 7 INPUT 7 SCALING VALUE
dISPLY 7 DISPLAY 7 VALUE
INPUt 8 INPUT 8 SCALING VALUE
dISPLY 8 DISPLAY 8 VALUE
INPUt 9 INPUT 9 SCALING VALUE
DISPLAY PARAMETER USER SETTING
dISPLY 9 DISPLAY 9 VALUE
INPUt 10 INPUT 10 SCALING VALUE
dISPLY 10 DISPLAY 10 VALUE
INPUt 11 INPUT 11 SCALING VALUE
dISPLY 11 DISPLAY 11 VALUE
INPUt 12 INPUT 12 SCALING VALUE
dISPLY 12 DISPLAY 12 VALUE
INPUt 13 INPUT 13 SCALING VALUE
dISPLY 13 DISPLAY 13 VALUE
INPUt 14 INPUT 14 SCALING VALUE
dISPLY 14 DISPLAY 14 VALUE
INPUt 15 INPUT 15 SCALING VALUE
dISPLY 15 DISPLAY 15 VALUE
INPUt 16 INPUT 16 SCALING VALUE
dISPLY 16 DISPLAY 16 VALUE
USEr User Input Parameters
DISPLAY PARAMETER USER SETTING
USrACt USER ACTIVE STATE
USEr-1 USER INPUT 1
USEr-2 USER INPUT 2
USEr-3 USER INPUT 3
F1 FUNCTION KEY 1
F2 FUNCTION KEY 2
SEC-F1 2nd FUNCTION KEY 1
SEC-F2 2nd FUNCTION KEY 2
